CY7C67300
Document #: 38-08015 Rev. *J Page 26 of 99
Watchdog Timer Register [0xC00C] [R/W]
Register Description
The Watchdog Timer register provides status and control over
the Watchdog timer. The Watchdog timer can also interrupt the
processor.
Timeout Flag (Bit 5)
The Timeout Flag bit indicates if the Watchdog timer expired. The
processor can read this bit after exiting a reset to determine if a
Watchdog timeout occurred. This bit is cleared on the next
external hardware reset.
1: Watchdog timer expired.
0: Watchdog timer did not expire.
Period Select (Bits [4:3])
The Period Select field is defined in Tab le 4 1. If this time expires
before the Reset Strobe bit is set, the internal processor is reset.
Lock Enable (Bit 2)
The Lock Enable bit does not allow any writes to this register until
a reset. In doing so the Watchdog timer can be set up and
enabled permanently so that it can only be cleared on reset (the
WDT Enable bit is ignored).
1: Watchdog timer permanently set
0: Watchdog timer not permanently set
WDT Enable (Bit 1)
The WDT Enable bit enables or disables the Watchdog timer.
1: Enable Watchdog timer operation
0: Disable Watchdog timer operation
Reset Strobe (Bit 0)
The Reset Strobe is a write-only bit that resets the Watchdog
timer count. Set this bit to ‘1’ before the count expires to avoid a
Watchdog trigger
1: Reset Count
Reserved
Write all reserved bits with ’0’.
Table 40. Watchdog Timer Register
Bit # 15 14 13 12 11 10 9 8
Field Reserved...
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 0 0 0 0 0
Bit # 7 6 5 4 3 2 1 0
Field
...Reserved Timeout
Flag
Period
Select
Lock
Enable
WDT
Enable
Reset
Strobe
Read/Write R/W R/W R/W R/W R/W R/W R/W W
Default 0 0 0 0 0 0 0 0
Table 41. Period Select Definition
Period Select[4:3] WDT Period Value
00 1.4 ms
01 5.5 ms
10 22.0 ms
11 66.0 ms
