Stellaris® LM3S9B96 Development Kit User’s Manual
January 12, 2010 9
Figure 1-1. DK-LM3S9B96 Development Board
On-board JTAG /SWD
Debug Interface
USB Connector for
Debug and/or Power
Stellaris
LM3S39B96
Microcontroller
CAN Bus Interface
3.5" LCD Touch Panel
USB connector with
Host, Device and
On-the-Go modes
10/100 Ethernet
User LED
microSD Card Slot
Potentiometer
5 VDC supply input
JTAG/SWD In/
Out Connector
User Switch
Reset switch
Power and
Ground Test
Points
3.00V Analog
Reference
Headphone Output
Audio Line Output
Microphone Input
Audio Line Input
1MB Serial Flash Memory
EPI Expansion Board
