CLUX-1H4CAT 1 by 4 HDMI to CAT 6 V1.
Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this product near water.
Table of Contents 1. Introduction ……………………..……………………...…........….……. 1 2. Applications …………………..………………….……...................….. 1 3. Package Contents ………………………...........……….................… 1 4. System Requirements ……………..……….........………............……. 1 5. Features …………………………………………......……........…...…… 2 6. Specifications ………………………………...……..........………....…. 3 7. Operation Controls and Functions ……………...……..............…… 7.1 Front Panel .............................................
1. Introduction The 1 by 4 HDMI to CAT6 1.3 splitter when used with CAT6 to HDMI receivers it will allows user to distribute a HDMI over 45 meters through CAT6 cables over 45 mters This solution provides a direct input of one HDMI to a looped output of HDMI and 3 CAT6 outputs – a smart way to link and display a single source to 4 different screens simultaneously.
5. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant Deep color video up to 12bit, 1080p@60Hz Allows users to link up to four displays HDCP keysets allows each output to work independently when connected to a HDMI display Supports both DVI source/display by using HDMI to/from DVI adaptor cable Supports LPCM 7.
6. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Ports 1 x HDMI female port (Type A connector) Output Ports 3 x CAT6 output Video/3 x CAT6 output DDC 1 x HDMI female port (Type A connector) EDID STD / TV HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.
7. Operation Controls and Functions The following sections describe the hardware components of the unit with installation and functionality. 7.1 Front Panel ① ② ③ ④ ⑤ ① HDMI/DVI indicators: When the LED turns on this means the input source is HDMI and when the input source is DVI the LED will not turn on. ② HDCP indicators: When the input source has HDCP protection the HDCP LED will turn on. ③ SYNC Indicator: The LED will turn on when the input source's signal is detected by the device.
③ EDID Control Switcher: Switch the EDID between STD & TV. Switch to STD to use the built-in EDID or switch to TV to use TV’s EDID. Default factory setting is on TV, leave as is when the display is working properly. Note: 1. When EDID is switched to TV, the unit will detect the first HDMI output EDID and record in the unit. If the first detected output source is DVI it will pass on to the next one until the first HDMI source been detected. The detection priority is HDMI v1.3 > HDMI v1.2 > DVI. 2.
8. Pin Definitions 8.1 IR Cable Pin Definition IR Blaster IR Receiver ① Power 5V ② NC ③ IR blaster signal ① IR signal ② Power 5V ③ Grounding ① ②③ ① ②③ Note: The frequency on both IR Receiver & Blaster can support 20~60KHz. 8.
DVD 7 DDC AorBorC CAT6 OUTPUT IR Blaster DVD IR Blaster IN IR Receiver HDMI HDMI Cable HDMI HD TV VIDEO DDC x3 CAT6 OUTPUT AorBorC OUT CLUX-1H4CAT CLUX-1H8CAT HDMI DVD HDMI Cable DDC AorBorC CAT6 OUTPUT HDMI VIDEO HD TV CAT6 IN CH-106TX CH-1106TX CLUX-1H4CAT CLUX-1H8CAT CMLUX-4H4CAT CLUX-22HC CLUX-22HC HDMI IN HDMI HDMI HDMI IN HDMI CH-106TX CH-1106TX VIDEO 9.
HDMI 30° 3M 7M IR Receiver HD TV 30° 3M HDMI HDMI Cable VIDEO AorBorC CAT6 OUTPUT DDC HDMI Cable B HDMI 30° 3M HD TV 30° 3M 7M IR Receiver CLUX-1CAT4H / CLUX-1CAT8H VIDEO AorBorC CAT6 OUTPUT HDMI HD TV HDMI Cable C CLUX-22HC DDC A HDMI CH-106RX / CH-1106RX HDMI 8
Acronyms Acronym Complete Term CAT6 Category 6 cable DVI Digital Visual Interface EDID Extended Display Identification Data HDCP High-Bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television IR Infrared LPCM Linear Pulse Code Modulation STD Standard SYNC Synchronize SXGA Super Extended Graphics Array VGA Video Graphics Array A
