CY8C24223A, CY8C24423A
Document Number: 38-12029 Rev. *L Page 29 of 34
Figure 16. 28-Pin (210-Mil) SSOP
Thermal Impedances Capacitance on Crystal Pins
Solder Reflow Specifications
The following table shows the solder reflow temperature limits that must not be exceeded.
51-85079 *E
Package Typical
JA
[17]
20 SSOP 117 C/W
28 SSOP 101 C/W
Note
17. T
J
= T
A
+ POWER x
JA
Package Package Capacitance
20 SSOP 2.6 pF
28 SSOP 2.8 pF
Package Maximum Time above T
C
– 5 °C Maximum Peak Temperature
20 SSOP 30 seconds 260C
28 SSOP 30 seconds 260C
