DELUXE REMOTE IMMOBILISER USER INSTRUCTIONS CYCL PS SECURITY SYSTEMS PROUDLY AUSTRALIAN
Contents Page Introduction 2 ! Silent arming 3 ! Panic Operations ! Horn Connection ! Central Locking ! Remote controls ! ! ! ! ! ! ! ! ! ! ! 3 Arming/Disarming 3 Automatic Arming 3 Dome Light Function 4 Immobilisation 4 Emergency Override 4 Override Procedure 5 Programmable Options 6 Program Options Table 6 Program Options Desc’ 7 Changing PIN Code 9 Battery Replacement 10 Optional Features ! Boot release ! Anti-hijacking ! Electric window closer ! Diagnostics 10 11 11 11 11 12 12 12 12 Spec
CYCLOPS PARALYSER 355 ENGINE IMMOBILISER CYCL PS SECURITY SYSTEMS Introduction Congratulations on having one of the world's most advanced engine immobilisers installed in your vehicle. The CYCLOPS P355 meets Australian Standards AS/NZS 4601. The P355 uses high security, high reliability circuitry to disable your car’s engine. The P355 is designed as a modular system, and so by adding an approved siren, sensor and switch connections, the P355 can be upgraded to a fully featured alarm system.
OPERATIONS REMOTE CONTROLS LED The P355 is supplied with two rolling code remote controls. Each time a button is pressed, the code rolls to a new code. Each code is never used twice. A small green Light Emitting Diode (LED) will light when a remote control button is pressed. MAIN BUTTON SECONDARY BUTTON ARMING AND DISARMING KEYRING To arm or disarm the system, press the main button on the remote control. The vehicle’s indicators will confirm a valid remote operation.
DOME LIGHT FUNCTION When the P355 is disarmed by remote control, the internal circuitry will switch on the car’s dome light for 30 seconds. This feature will be cancelled if the driver turns the ignition switch to the ON position. Factory setting is disabled (see page 7 for details) IMMOBILISATION The P355 includes two independent circuits of immobilisation. Each circuit starves the engine of one of it’s critical power supplies.
OVER-RIDE PROCEDURE To illustrate the PIN over-ride procedure we will assume a PIN of 4,3,2,1. 1. If indicators are already flashing (and horn is sounding - see Optional Features: HORN) allow the system to reset with all doors closed. 2. Turn ignition switch to ON position, the status LED will remain lit. 3. Turn ignition switch to the ACC position and count the LED flashes. 4. Turn ignition switch ON when the 4th flash has extinguished. 5. Turn back to ACC position and count 3 flashes, switch ignition ON.
PROGRAMMABLE OPTIONS The P355 includes 9 programmable options which alter the system functions to comply with the user’s preferences and vehicle special needs. Changing an option setting is as simple as ! Switch the ignition key ON a certain number times (this number corresponds to the option number). ! Press the remote control after the prompt from the vehicle’s indicators. After the remote press the indicators will flash either once or three times to show the result of the option change.
PROGRAMMABLE OPTION DESCRIPTIONS Option #3** the Anti Hijack feature locks the car doors when the ignition is switched on, except when a connected door is open. The anti hijack feature unlocks the doors when the ignition is switched off (when driver has reached destination). The feature is disabled if the dome light illumination is extended by a vehicle timing circuit. ! Option #7 programming remote isn't strictly an optional feature. This feature is used if a spare remote is purchased.
PROGRAMMABLE OPTION DESCRIPTIONS cont’ Option #13** sets the system to always arm/disarm in silent mode. The standard indicator flashes will accompany each arm/disarm command, but the siren will remain silent. ! Option #15** enables the auto-relock feature. The doors will automatically re-lock when the vehicle has been disarmed by remote control and the doors remain closed for more than 120 seconds. ! Option #17** is used to extend the time length of the central locking pulses.
CHANGING PIN CODE To alter the PIN code of the system, follow the standard option change procedure; select option #19. ! The vehicle indicators will flash twice to inform you that the system is ready to accept the new PIN. The “time-out” is set to two seconds. If the programming has not begun before then, the system will drop-out of programming mode. ! Enter the new digits by momentarily pressing the main button on a valid remote control. The vehicle indicators will flash in response to each press.
BATTERY REPLACEMENT Using a flat head screwdriver to carefully CASE TOP separate the two body housings taking care not to disturb the circuit board. Remove the old batteries whilst paying attention to the orientation of the positive and negative terminals. Insert new batteries in identical fashion to the original and reassemble remote. Test remote control by pressing main button. REMOVE BATTERIES For further information, please IN THIS DIRECTION contact your local Cyclops service centre.
HORN CONNECTION The P355 includes circuitry to sound the car horn relay. The car horn will toot to confirm arming / disarming. The car horn will pulse for thirty seconds if a thief opens the door after the system was armed by remote. TEMPORARY SILENT ARMING The second button on the remote control can be used to cancel the car horn confirmation*. To cancel car horn toots for one operation, press the second button momentarily before pressing the main button.
BOOT RELEASE Press the second button on the remote control and keep it depressed until the boot releases*. This will take about three seconds. A successful boot release signal will disarm the alarm and flash the vehicle indicators four times. This function can only operate if the vehicle is equipped with an electrical boot release. ANTI HIJACK Two seconds after the ignition is switch to the ON position, the P355 will lock the cars doors.
SPECIFICATIONS Manufactured by Model Number Standards met Supply voltage Current consumption Country of manufacture RF Transmission Freq Dynamco Pty Ltd. P355. AS/NZS 4601 +9VDC - 15VDC. less than 20mA (while armed). China (in Dynamco’s ISO-9002 facility). 433MHz TROUBLE SHOOTING System won't arm. LED on dash won't flash. ! ! ! Make sure that ignition switch is in the OFF position. Ensure the vehicle battery is not flat. Try your spare remote transmitter unit.
WARRANTY The Dynamco range of Cyclops Security Systems is covered by an extensive two year warranty (parts & accessories one year). In the unlikely event of a faulty system Dynamco will either replace or repair the system at no cost during the 2 year period. The warranty does allow for the following conditions ~ Subject to the conditions stated below, Dynamco Pty Ltd warranty the product to be free from manufacturing defects and faulty material within the warranty period stated.
WARRANTY REGISTRATION PURCHASED FROM OWNER’S NAME TYPE OF VEHICLE VEHICLE REGO MODEL OF UNIT P.I.N DATE OF MANUFACTURE DATE OF INSTALL’ WARRANTY PERIOD CONTROL MODULE SIREN & REMOTES INSTALLER’S NAME AFTER HOURS EMERGENCY PHONE - Page 15 - . . . . CYCL PS SECURITY SYSTEMS . . . . . . .
