Product Data Sheet / Brochure

OR700LCDRM1U Smart App LCD UPS
Cost-eective feature-rich power protection for networking, servers and telecommunications equipment.
©CyberPowerSystems(USA)IncAllrightsreservedCyberPowerreservestherighttochangewithoutpriornoticeproductofferingsorspecifications
GENERAL
UPS Topology Line Interactive
Energy Saving GreenPower UPS™ Bypass Technology
ENERGY STAR® Qualified Yes
INPUT
Voltage 90Vac - 140Vac
Frequency 57Hz - 63Hz
Plug Type NEMA 5-15P
Plug Style Straight
Cord Length 10'
OUTPUT
VA 700
Watts 400
Automatic Voltage Regulation Yes
On Battery Voltage 120Vac ± 10%
On Battery Frequency 60Hz ± 1%
On Battery Waveform Simulated Sine Wave
Outlets - Total 6
Outlet Type NEMA 5-15R
Outlets - Battery & Surge Protected 4
Outlets - Surge-Only Protected 2
Overload Protection
Internal circuitry limiting / circuit
breaker
Transfer Time 4ms
BATTERY
Runtime at Half Load (min) 11
Runtime at Full Load (min) 3
Battery Type Sealed Lead-Acid
Battery Size 6V/9AH
Replacement Battery RB0690X2
Battery Quantity 2
User Replaceable Yes
Typical Recharge Time 8 Hours
SURGE PROTECTION & FILTERING
Surge Suppression 1,030 Joules
Phone RJ11 / Ethernet RJ45 1-In, 1-Out (Combo)
EMI/RFI Filtration Yes
MANAGEMENT & COMMUNICATIONS
Multifunction LCD Panel
Displays: Current/Load Level,
Runtime, Battery Level, Input Voltage,
Output Voltage, Battery In Use,
Overload, Silent Mode, Normal Mode
HID Compliant USB Port Yes
Serial Port Yes
Management Cable USB Cable, Serial Cable
Audible Alarms
Battery Mode, Battery Low, Overload,
UPS Fault, Replace Battery
Software PowerPanel® Business Edition
SNMP / HTTP Remote Monitoring
Yes, with optional RMCARD202,
RMCARD203 or RMCARD205
PHYSICAL
Rack Size 1U
Form Factor Rack
Dimensions (WxHxD) (in.) 17.25 x 1.75 x 9.25
Weight (lbs.) 18.5
ENVIRONMENTAL
Operating Temperature 32°F to 95°F / 0°C to 35°C
Operating Relative Humidity 0% - 95% non-condensing
CERTIFICATIONS
Safety UL1778, cUL 107.1, FCC DOC Class B
Environmental RoHS Compliant
WARRANTY
Product Warranty 3 Years Limited
Connected Equipment Guarantee Lifetime
CEG Amount $300,000
