1.8 Ordering Information
This section provides the ordering information for the 603. Note that the individual part numbers correspond
to a specific combination of 603 internal/bus frequencies, which must be observed to ensure proper
operation of the device. For other frequency combinations, temperature ranges, power-supply tolerances
package types, etc., contact your local Motorola or IBM sales office.
1.8.1 Motorola Part Number Key
Figure 15 provides a detailed description of the Motorola part number for the 603.
Figure 15. Motorola Part Number Key
1.8.2 IBM Part Number Key
Figure 16 provides a detailed description of the IBM part number for the 603.
Figure 16. IBM Part Number Key
Table 11. Ordering Information for the PowerPC 603 Microprocessor
Package Type
Internal
Frequency
Bus
Frequency
Required
PLL_CFG
[0–3]
Setting
Part Numbers
Motorola IBM Motorola IBM
Wire-bond
CQFP
C4-CQFP 80 MHz 40 MHz 0100 MPC603AFE80CX PPC603-FX-080-2
66.67 MHz 33.33 MHz 0100 MPC603AFE66CX PPC603-FX-066-2
66.67 MHz 0000 MPC603AFE66AX PPC603-FX-066-1
MPC 603 A FE XX X X
Product Code
Part Identifier
Part Modifier
Bus Divider
Processor Speed
Package
(A = Alpha—Original Design)
(FE = Wire-Bond CQFP)
(A = 1:1 Processor to Bus,
C = 2:1 Processor to Bus)
Revision Level
(Contact a Local Motorola Sales Office)
(F = C4-CQFP)
Part Identifier
PPC 603 – F X– 0XX– X
Package
Revision Level
Bus Speed
Internal Speed
(Contact a Local IBM Sales Office)
(1 = Internal Speed,
2 = Half Internal)
Product Code
