CS150U48V3 Installation & Operation Manual K01-1504801-00
TABLE OF CONTENTS 1 Product introduction.............................................................................................................. 3 1.1 General Description...................................................................................................................... 3 2 Important Safety Notes ......................................................................................................... 3 2.1 Electrical Warnings.........................................................
TABLE OF TABLES Table 1: Battery Heater Specifications .............................................................................................. 11 Table 2: Block Diagram Descriptions ................................................................................................ 11 Table 3: AC Line Cord ....................................................................................................................... 12 Table 4: Conduit Wires .......................................................
1 PRODUCT INTRODUCTION 1.1 General Description The CS150U48V3 battery backup unit is designed to serve up to two MDU ONTs (Optical Network Terminal for Multi-Dwelling Use) and can be installed indoors or outdoors.
2.2 Battery Warnings • Danger of explosion if battery is incorrectly connected or replaced. • Worn-out or damaged batteries are considered environmentally unsafe. Always recycle used batteries or dispose of the batteries in accordance with all federal, state and local regulations. • Do not open or mutilate batteries. Any gel or liquid emissions from the sealed lead-acid (SLA) battery contain sulfuric acid, which is harmful to the skin and eyes. Emissions are electrically conductive and corrosive.
DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT OR OTHER HIGH RISK ACTIVITIES. CyberPower does not sell the PRODUCT for use in high-risk activities.
3 DIMENSIONS 17.14 inch (435.4 mm) 15.75 inch (400.1 mm) 7.09 inch (180.1 mm) 5.79 inch (147.1 mm) 15.30 inch (388.6 mm) 16 inch (406.4 mm) Figure 1: Dimensions (Front View) 15.04 inch (382 mm) 15.75 inch (400.1 mm) 9.06 inch (230.1 mm) Figure 2: Dimensions (Side View) © 2010 CyberPower Systems (USA), Inc. All Trademarks are property of their owners.
4 INSTALLATION 4.1 Overview 1 2 4 3 5 8 6 12 7 10 9 6 11 Figure 3: Unit Overview (Front) 13 1. Internal AC power wiring inlet 2. Alarm Silence and Cold Start button 3. LED Indicators (AC/DC MODE, BATTERY MISSING 1, BATTERY MISSING 2, DC OUTPUT) 4. DC Output and Telemetry receptacles 5. Battery wiring harness plug-in 6. Door clasp 7. Door padlock hasp 8. Door ground and bonding stud 9. Battery tray mounting screw 10. Battery tray 11. Customer option ground stud 12. Wire management bracket 13.
4.2 Unpacking Inspect the Battery Backup Unit upon receipt.
4.4 Installation 4.4.1 Wall Mounting the UPS 1. Remove the UPS from the carton. 2. Get the wall mount kit. 3. Use the nuts included in the kit. Attach both wall mount brackets to the threaded posts on the back side of the UPS enclosure as shown on the right. 4. Reference the Wall Mount Chart (scaled-down) in Appendix I to mark the four mounting hole locations. 5. Pre-drill the marked hole locations to a suitable size (M8 is recommended) for the fasteners being used. 6.
4.5 Installing the Battery Trays (Battery Replacement) The batteries must be installed and wired to the battery tray prior to installing inside the UPS enclosure. 1. Slide the battery tray out of the UPS. 2. Get the new batteries and install batteries onto the battery tray as shown below. Battery Jumpers Secure harness with cable ties Wire Strain Relief Wire Harness (Vo+) Wire Harness (Vo-) Battery tray mounting hole Figure 10: Battery Wiring 3. Install the battery clamp using the (4) screws provided.
4.6 Battery Heater - BTH-150-8X (Optional) Heater Input Voltage Wattage Line Cord Thermostat Thermal Fuse Mat Mounted Thermostat 44 33 2 1 (AC) 110V/60Hz 120W OPEN：15˚C CLOSE：5˚C 84˚C OPEN：50˚C CLOSE：35˚C Table 1: Battery Heater Specifications Figure 12: Block Diagram of Battery Heater Note: Make sure that the input voltage for the battery heater is 110V.
4.7.2 Outdoor Power Cord Selection 1. If an outdoor AC Line cord is selected to connect the unit to AC wall outlet, be sure that the selection criterion in the following table are fully complied. Outdoor Use Cord Rating Wire (AWG) Three conductors, current rating 10A, VW-1, 105℃, 125/250V Check specifications of liquid tight cable gland to determine the outside diameter of the wire. (O.D. > 6.8mm; 18AWG min.
4.8 ONT Alarm Connections 1. Route the 7-wire cable back from the ONT enclosure to the UPS. 2. Remove any convenient 3/4” knock-out of the UPS enclosure. 3. Install a strain relief in the knock-out hole. 4. Route the power cable up through the strain relief. 5. Trim the cable to the desired length and strip back approximately 2” of the jacket. 6. Using a jeweler’s standard blade screwdriver, attach the wires to the connector referencing the ONT pin-out information. 7.
5.2 Controls and Operational LEDs Four status LEDs are displayed on the front panel of the UPS. The operation of the UPS can be assessed using these LEDs. Indicator Color Condition Black Press and hold the button for 1 second to silence the audible alarm for 24 hours. Press and hold the button for 10 seconds to shut down the output voltage. The UPS will restart after 15 seconds.
5.3 Alarms There are audible and visual alarm signals to alert the customer to abnormal and/or service affecting conditions present in the UPS.
6 SPECIFICATIONS Model Number Input: Rating Voltage/Frequency Input Voltage Range Frequency Range P.F.
7.09 inch (180 mm) APPENDIX I - Wall Mount Chart 16 inch (406.4 mm) Recommended Screw Dimensions M8 x 25L or 3/8” x 1”L © 2010 CyberPower Systems (USA), Inc. All Trademarks are property of their owners.
