INSTRUCTION MANUAL Before using the TV, please read this manual thoroughly, and retain it for future reference.
English CONTENTS 1 SAFETY PRECAUTION 1 2 IMPORTANT SAFETY INSTRUCTION 2 3 ACCESSORIES 3 4 GETTING STARTED 3 5 CONTROL REFERENCE GUIDE 6 CONNECTIONS 7 WALL MOUNT INSTALLATION 8 9 Remote Control Front Frame Back Frame Side Panel 4 5 5 6 Antenna Connection S-Video Connection AV Connection Y Pb Pr Connection HDMI Connection VGA Connection Headphone Connection Power Cord Connection 7 7 7 8 8 9 9 9 10 INITIAL SETUP Putting The Unit On A Proper Place Source Selection Turning The Unit On
CONTENTS 10 DISPLAY MODE PC Formats Video Formats 25 26 11 SPECIFICATION 27 12 TROUBLESHOOTING GUIDE 28 SAFETY CLASS :This is an IEC safety class I product and it must be grounded for safety.
SAFETY PRECAUTION * CAUTION MARKING WAS LOCATEDAT BOTTOM PLACEMENT INFORMATION ENCLOSURE OF THEAPPARATUS. • Do not use this unit in places that are extremely hot, cold, dusty or humid. • Do not restrict the airflow of this unit by placing it somewhere with poor airflow, by covering it with a cloth, by placing it on bedding or carpeting. SAFETY INFORMATION • When connecting or disconnecting the AC power WARNING:TO REDUCE THE RISK OF ELECTRIC cord, grip the plug and not the cord itself.
IMPORTANT SAFETY INSTRUCTIONS 1)Read these instructions. 2)Keep these instructions. 3)Heed all warnings. 4)Follow all instructions. 5)Do not use this apparatus near water. 6)Clean only with a dry cloth. 7)Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (Including amplifiers) that produce heat.
ACCESSORIES Please check and identify the supplied accessories. Remote control ..................................................................................................................x 1 Battery(AA) ............................................................................................................ .........x 2 Warranty Card ................................................................................................................ x 1 Instruction Manual ..............................
CONTROL REFERENCE GUIDE REMOTE CONTROL 1.STANDBY To switch on the Tv or make the TV into standby mode. 2.MUTE Press this button to mute or restore sound. 3.INFO Show the information of the program you are watching. 4.SOURCE Press this button to select an input source. 5.PMODE Press this button to select a picture mode for different picture qualities. 6.SMODE Press this button to select sound setting for different sound effects. 7.0-9 Allows you to change the channel of the TV. 8.
CONTROL REFERENCE GUIDE FRONT VIEW 1.Color LC D Screen 2.Remote Sensor Do not block this sensor or the remote control will not work. 3.Standby Indicator Indicates whether the unit is ON or in STANDBY (OFF) mode. Light in red: The unit is in STANDBY. Light in green:The unit is turned ON. 4. Speakers 1 4 42 3 BACK VIEW 1.TV ANTENNA Terminal 2.HEAD PHONE Jack 3.AUDIO IN Jack (Right) 4.AUDIO IN Jack (Left) 5.VIDEO IN Jack 6.S-VIDEO Jack 7.Y / PB / PR Jacks 8.PC AUDIOIN Jack 9.VGA IN Jack 10.
CONTROL REFERENCE GUIDE FRONT VIEW 7 6 5 4 VOL- VOL+ CH- CH+ 3 2 MENU SOURCE 1 STANDBY 1. STANDBY Button Press toturn the unit on and off. 2. SOURCE Button Press to select the input source of the TV . 3. Menu Button Press to display the on-screen TV menu. 4. CH+ Button Press to change the TV channels and up highlight selections on the menu screen. 5. CH- Button Press to change the TV channels and down highlight selections on the menu screen. 6. VOL+ Button Press to adjust the volume up.
CONNECTIONS CONNECTING A TV ANTENNA / CABLE / SATELLITE To view television channels correctly, a signal must be received from one of the following sources: - An indoor or outdoor aerial antenna - A cable system - A satellite system NOTE For receiving over-the-air TV broadcasts, we recommend that you use an external fixed antenna. Should you require the use of a temporar y antenna, please ensure that you purchase an antenna with sufficient ability to receive in weak signal areas.
CONNECTIONS CONNECTING A HIGH-DEFINITION (HD) SOURCE USING COMPONENT CONNECTION High-Definition (HD) Devices with component video output must be connected to the YPbPr input. Connect the component video cable and audio cable (not included) as shown. Make sure you connect the component video cable and audio cable from the other equipment ( COMPONE OUT and AUDIO OUT ) to this unit COMPONENT IN and AUDIO I N ).
CONNECTIONS CONNECTING A PC Connect the 15-pin D-SUB PC/VGA connector from your computer to the 15-pin D-SUB PC/VGA input on this unit using a monitor cable and an audio cable (not included) as shown. Make sure you connect the cable from the computer ( VGA and AUDIO - PC OUT ) to this unit ( VGA and AUDIO - PC IN ). CONNECTING HEADPHONES • Turn down the volume before connecting headphones to the unit, then adjust the volume to your desired level.
WALL MOUNT INSTALLATION INSTALLING / REMOVING THE BASE STAND WARNING : The LCD D isplay i s v ery f ragile , and m ust b e p rotected a t a ll t imes w hen r emoving t he b ase Stand . Be sure that no hard or sharp object , or anything that could scratch or damage the LCD display, comes into contact with it . Do NOT exert pressure on the front of the unit at any time because the screen could crack . 1 . Disconnect all cables or cords connected to the unit . 2 .
INITIAL SETUP PUTTING THE UNIT ON A PROPER PLACE When you turn on your television set for the first time, be sure to place it on a solid stable surface. To avoid danger, do not expose the TV to water, or a heat source (e.g. lamp, candle, radiator). Do not obstruct the ventilation grid at the rear and be sure to leave sufficient gaps around the unit. SOUR CE SELECT ION 1. Press the SOUR CE button on the remo te control. 2.
INITIAL SETUP How to Navigate Air Mode: Select AIR when connected to an indoor/outdoor antenna. Cable Mode: Select CABLE if you subscribe to a pay television service includ ing satellite. 12 12 6 6 Picture Audio Tim e Setup LOCK Picture CHANNEL Favorite Favorite Show Hide Show Hide Cable Channel No Channel No KOCE LB Channel label Channel label DTV Signal DTV Signal Move Select MENU Move Exit Select Tim e Exit 12 6 6 Audio MENU Using the ◄► b utton to highlight CABLE.
T V SETUP Pict ure PICTURE MENU The PICTURE menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select PICTURE.
T V SETUP Pict ure PICTURE MENU The PICTURE menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature. Press the MENU button on the remote control. Navigate using the ◄► b uttons to select PICTURE.
T V SETUP Audio AUDIO MENU The AUDIO menu offers options to make sound enhancements while listening through the built-in speakers and personal preferences. Adjustment options include bass, treble, balance, surround and audio language. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select AUDIO. 12 Press the ▼ b utton to highlight SoundMode, then press the ► b utton to select your sound preference from 4 factory options: STANDARD > MUSIC > MOVIE > PERSONAL.
T V SETUP Audio AUDIO MENU The AUDIO menu offers options to make sound enhancements while listening through the built-in speakers and personal preferences. Adjustment options include bass, treble, balance, surround and audio language. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select AUDIO.
T V SETUP 12 6 Tim e TIME MENU The TIME menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust automatically after the initial Channel Auto Scan of available broadcast channels in your area. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select Time.
T V SETUP Setup SETUP MENU In the SETUP menu you may change the initial set up of preferences that include settings for language, menu display, computer monitoring, closed captions, enhancement of black detail in the picture and resetting your TV back to its factory default status. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select SETUP.
T V SETUP Setup SETUP MENU The SETUP menu includes adjustments for activating the Closed Caption feature for display on the television and customizing CC display types and font styles.
T V SETUP Setup SETUP MENU In the SETUP menu you may adjust the position of images displayed on screen once you connect an input signal from your PC. Recommended resolution is 1366 x 768. If your PC system uses a standard signal mode, the screen will adjust automatically. Connect an optional 3.5mm audio cable for stereo sound. How to Navigate: After connecting to a PC, press the SOURCE button and highlight VGA, then press the ENTER button.
T V SETUP Lock PARENTAL MENU In the PARENTAL menu you may block television by inputting passwords. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select Parental.
T V SETUP PARENTAL MENU Lock In the PARENTAL menu you may block television and movie programming based on U.S TV and movie rating guidelines. To gain ac cess and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select Parental. Press the ▼ b utton to highlight ENTER PASSWORD. Enter your 4 digit code (factory default code is "0000") unless previously changed.
T V SETUP Lock PARENTAL MENU In the PARENTAL menu you may block television and movie programming based on Canadian TV and movie rating guidelines. To gain ac cess and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. Navigate using t he ◄► b uttons to select Parental. Press the button to highlight ENTER PASSWORD. Enter your 4 digit code (factory default code is "0000") unless previously changed.
T V SETUP TV MENU Channel The TV menu provides for the setup of your television to receive TV channels, store your favorites, add or skip channels and label them by their call letters. How to Navigate: Press the MENU button on the remote control. Navigate using the ◄► b uttons to select TV. Press the ▼ b utton to highlight your preferences.
DISPLAY MODE PC FORMATS Res o l ut io n 640 X 480 H or i z o nt a l Sc an ning F r eq u en cy (KHz) Vert i c a l Sc an n i n g Fr e qu e ncy (Hz) 31. 5 6 40 X 4 8 0 6 40 X 480 8 00 X 600 8 00 X 6 0 0 800 X 6 0 0 800 X 6 0 0 1 024 X 7 68 10 24 X 7 68 1 0 24 X 7 68 13 6 6 X 76 8 47. 7 1920 X 1080 66.6 NOTE: This product does not support the display mode not listed above. In order to achieve the best display effect, please select the above-listed 11 display modes input signal.
DISPLAY MODE VIDEO FORMATS SUPPORTED COMPONENT / HDMI INPUT MODE R e solut i on Horizontal Scanning Frequency Vertical Scanning Frequency (Hz) Format 720 X 480 31. 47 59. 94 480 i 720 X 480 15. 734 59. 94 480 p 1280 X 720 37. 5 50 720 p 1280 X 720 45 60 720 p 1920 X 1080 31.25 50 1080 i 1920 X 1080 33.75 60 1080 i 24 1080 p 1920 X 1080 27 1920 X 1080 56. 25 50 1080 p 1920 X 1080 67.
SPECIFICATION Model Description Panel Systems Panel Type Diagonal Size Screen Format Resolution Brightness Contrast View Angle Response Time Maximum Color Color System Sound System Audio System Sound Output LCD Panel 24 inches 16:9 1920 x 1080 300 nit 1000 : 1 170(H)/160(V) 5 ms 16.7 M colors ATSC/QAM/NTSC M BTSC RF Input 75 ohm external terminal Video: 480i, 480p, 720p, 1080i, 1080p. Audio: Two channel linear PCM 32, 44.1 and 48kHz, 16, 20 and 24 bits D-sub 15pin G: 0.7Vp-p, 75ohms B: 0.
TROUBLESHOOTING GUIDE SYMPTOM TV Bad Picture (snow, multiple images distortion,blurry) No sound. CAUSE (AND REMEDY ) • • • • • Check the location of the antenna and adjust it if necessary. Make sure the antenna cable is firmly connected. Make sure all input cables are firmly connected. Increase the volume. Check whether the mute function has been activated on the Remote Control. Black and White picture. • Check the PICTURE setting within the PICTURE menu.
