4. Operation 7-2018
58 A045R242 (Issue 12)Copyright © 2018 Cummins Inc.
FIGURE 24. MANUAL START SCREEN, STANDARD OPERATOR PANEL
3. The generator set starts and provides voltage to the transfer switch.
4. The generator set provides a signal to the transfer switch to transfer the
building load to the generator set.
FIGURE 25. BUILDING LOAD TRANSFER IN PROCESS
5. The transfer switch switches the generator set power to the building load.
The building is now running on generator power.
