3. Control System 7-2018
40 A045R242 (Issue 12)Copyright © 2018 Cummins Inc.
NOTICE
Adjusting the brightness on the operator panel adjusts the brightness of
both the LCD backlight and the LEDs on the display. The contrast should
never be 0 or 100% on any of the screens. The default value for Brightness is
50%.
3.6 History and About Menu
To access the History/About screen:
1. From any Information Menu, hold down the up and down arrows simultaneously
for two seconds. The Service Menu appears.
2. Select History/About.
3. Advance through the screens to view information about the generator set,
control, and display.
NOTICE
The following screens represent the standard operator panel (HMI211). If
using an in-home operator panel, which may be additionally purchased as an
option, the screens may look slightly different. This procedure applies to
both operator panels.
