3. Control System7-2018
35A045R242 (Issue 12) Copyright © 2018 Cummins Inc.
• Press Save to save any changes. After saving, the Save button changes to the
Adjust button.
FIGURE 6. TIME SETUP SCREEN
Updating Daylight Saving Adjust Screens
Update Values on the Daylight Saving Adjust Screen
1. From any Information Menu, hold down the up and down arrows simultaneously
for two seconds. The Service Menu appears.
2. Navigate to the Genset Service Menu.
3. Select Clock Exerciser to access the Time Setup screen.
4. Press the down key on the Time Setup screen to access the Daylight Saving
Adjust screen.
5. Select Adjust. When updating these settings, the functions of the keys are as
follows:
TABLE 19. KEY FUNCTIONS ON THE DAYLIGHT SAVING ADJUST SCREEN
Key/Button Function
Horizontal right arrow key Select successive blocks for editing settings on the screen
Left arrow key Return to the previous screen
+ or - keys Adjust values on the Adjust screen of the Daylight Saving Adjust
screen
Save button Save any changes; after saving, the Save button changes to the
Adjust button
