2. Introduction7-2018
17A045R242 (Issue 12) Copyright © 2018 Cummins Inc.
TABLE 7. GENERATOR SET WEIGHT 60 HZ, 1800 RPM
Sound Level 1 (Wet) C20 N6 C22 N6 C25 N6 C30 N6 C36 N6 C40 N6
kg 503 503 520 580 615 646
lb 1109 1109 1147 1279 1356 1424
TABLE 8. GENERATOR SET WEIGHT 60 HZ, 3600 RPM
Sound Level 1 (Wet) C30 N6H C36 N6H C40 N6H C45 N6H C50 N6H C60 N6H
kg 514 567 635 635 635 648
lb 1134 1249 1399 1399 1399 1429
TABLE 9. ALTERNATOR SPECIFICATIONS 60 HZ, 1800 RPM
C20 N6 C22 N6 C25 N6 C30 N6 C36 N6 C40 N6
Alternator Brushless, 4-pole rotating field, single bearing
Power (kVa):
1-Phase 20 22 25 30 36 40
3-Phase 25 27.5 31.3 37.5 45 50
Rated Voltages (V):
1-Phase 120/240
3-Phase
120/240
120/208
277/480
347/600
TABLE 10. ALTERNATOR SPECIFICATIONS 60 HZ, 3600 RPM
C30 N6H C36 N6H C40 N6H C45 N6H C50 N6H C60 N6H
Alternator Brushless, 2-pole rotating field, single bearing
Power (kVa):
1-Phase 30 36 40 45 50 60
3-Phase 37.5 45 50 56.3 62.5 75
Rated Voltages (V):
1-Phase 120/240
