4. Operation 7-2018
62 A045R242 (Issue 12)Copyright © 2018 Cummins Inc.
FIGURE 32. BUILDING LOAD TRANSFER IN PROCESS
6. The transfer switch switches the generator set power to the building load.
The building is now running on generator power.
FIGURE 33. GENERATOR SET POWERING BUILDING LOAD
7. When the remote display Stop button is pressed, the transfer switch
switches back to utility power after a 5 minute retransfer delay.
FIGURE 34. BUILDING LOAD TRANSFER IN PROCESS
FIGURE 35. UTILITY POWERING BUILDING LOAD
8. The generator set runs for a 5-minute cooldown and shuts off.
