4. Operation7-2018
61A045R242 (Issue 12) Copyright © 2018 Cummins Inc.
FIGURE 30. MANUAL START SCREEN, IN-HOME OPERATOR PANEL
4. The generator set starts and provides voltage to the transfer switch, but
the transfer switch does not switch (allowing the voltage to go to the
building) until after a delay.
FIGURE 31. TIME REMAINING UNTIL TRANSFER SCREEN
5. Five seconds after starting, the generator set provides a signal to the
transfer switch to transfer the building load to the generator set.
