4. Operation7-2018
59A045R242 (Issue 12) Copyright © 2018 Cummins Inc.
FIGURE 26. GENERATOR SET POWERING BUILDING LOAD
6. Press the Off button to switch the load back to the utility power.
FIGURE 27. BUILDING LOAD TRANSFER IN PROCESS
FIGURE 28. UTILITY POWERING BUILDING LOAD
7. Normal operation resumes.
Remote Starting the Generator Set Sequence
If the generator set is remote started with the in-home operator panel
accessory, if equipped (the generator set is in Auto Mode), the sequence is as
follows:
1. In a normal operation, the utility power is running to the transfer switch
and then to the building load, and the generator set is off.
2. The generator set-mounted control (HMI211) is set in Auto Mode.
