3. Control System 7-2018
38 A045R242 (Issue 12)Copyright © 2018 Cummins Inc.
FIGURE 9. DAYLIGHT SAVING ADJUST END SCREEN
3.5 Brightness and Contrast
The Screen Adjust screen allows the contrast, brightness, and units to be set. To
access the Screen Adjust screen:
1. From any Information screen, hold down the up and down arrows
simultaneously for two seconds to gain access to the Service Menu screen.
2. Select Screen Adjust.
To adjust the contrast, brightness, or units from the Screen Adjust screen:
1. From the Screen Adjust screen, select Adjust to access the screen variables.
2. Press the right arrow to move between the variables.
3. Adjust settings, and press Save to save any changes.
When updating these settings, the functions of the keys are as follows:
• The horizontal right arrow key is used to select successive blocks for editing
settings on the screen.
• Select the left arrow to return to the previous screen.
• Adjust values by using the + or - keys on the Adjust screen of the Display
Setup screen.
• Press Save to save any changes. After saving, the Save button changes to the
Adjust button.
