7. Parts List
PNEG-1425 50" Galvanized Butterfly Fan 21
No. Part # Description Qty U/M
35 S-9351 Clip 7/8" x 43/64" HRCLP 34G 20
36 11-0342-WH Guard, 59" 50" Short Fan Paint 1
37 12-0274 Venturi, 50" Butterfly Metal (50-1/2" I.D.) 1
38 12-0481 Top Panel 50" Galvanized Fan 1
39 12-0482 Bottom Panel 50" Galvanized Fan 1
40 12-0483 Left Panel 50" Galvanized Fan 1
41 12-0484 Right Panel 50" Galvanized Fan 1
42 12-0306 50" Galvanized Butterfly Cone Panel 3
43 12-0311 50" Galvanized Butterfly Bottom Cone Panel 1
44 13-0103RS Propeller, 50" Galvanized (Solid Rivet) 1
45 15-0126 Motor 1.5 HP, 1 PH, 1725 RPM 50/60 Hz 1
46 16-0007 Pulley AL104 x 1" MXB Fans 1
47 16-0016 Sheave 1 Groove 3.45" Diameter x 5/8" Bore 1
48 16-0076 Bearing 1" Pillow Block AVS FA 2
49 16-0087 1" Shaft - Dual Key - Tensioner 1
50 16-0088 A-46 V-Belt, 48" Nominal Length 1
51 91-0057 Rotary Tensioner Assembly w/ Splash Guards 1
52 DC-1540 Decal, Danger/Warning 2
53 DC-1571 Decal Grease Instructions All BD Fans 1
54 DC-983 Decal, AVS Logo 10-1/2" x 2" 2
55 DC-995 Decal, Warning Shear Point 2
56 S-1054 Split Lock Washer 3/8" ZN 1
57 S-248 Flat Washer 3/8" USS ZN YDP Grade 2 4
58 S-10268 Flange Nut 5/16"-18 JS Grade 5 13
59 S-4336 Screw, MS 5/16"-18 x 1" THS ZN Grade 2 4
60 S-6606 Flange Bolt 5/16"-18 x 3/4" ZN Grade 5 13
61 S-7383 Nylock Nut 3/8"-16 ZN Grade 5 4
62 S-7419 Screw, SDS #10-16 x 1-1/4" HWH SS 6
63 S-8978 Screw, TCSF #10-32 x 1/2" HWH ZN 40
64 S-9168 Square Key 1/4" x 1" 2
65 S-9303 Flange Bolt 3/8"-16 x 1-1/2" YDP Grade 8 5
66 PNEG-1425 50" Galvanized Butterfly Fan Instruction Manual 1
