Technical Specifications
1. AH110 Technical Specifications
Please refer to the AH110 Technical Datasheet” for full details on the technical specifications. Below are
key specifications for AH110.
AH110 Device Specifications
Dimensions (W x L x H)
7.5 x 7.5 x 4.2 mm
Weight 0.5g
Thermal Reaction Time τ: 11.7 (1-e
-t
)
Thermal Mass TBD
Operation Temperature 10˚C - 55˚C
Optical Interface Temperature 20˚C - 30˚C
Storage Temperature 10˚C - 30˚C
Battery Lifetime
1 min interval: 5 weeks
5 min interval: 26 weeks
30 min interval: 2 years
Storage Lifetime 1 Year
Wireless Communication Optical RX, RF TX
Packaging Material Biocompatible Epoxy and Parylene Coating
AH110 Temperature Sensor Specifications
Resolution
0.05°C
Inaccuracy, 25-45°C ±0.1°C
Inaccuracy, 10-55°C ±0.2°C
Measurement Interval 5s to 1 Hour (Configurable)
Measurement Timing Accuracy 1%
