Zusatz-Bedienungsanleitung Supplementary Instructions CUBE EPO Pedelec Bitte lesen Sie vor der ersten Fahrt die Seiten 7 bis 9! Führen Sie vor jeder Fahrt die Funktionsprüfung auf Seite 10 bis12 durch! Lesen Sie unbedingt auch Ihre allgemeine CUBE-Bedienungsanleitung! Please read page 7 to 9 before your first ride! Please perform the functional check on pages 10 to 12 before every ride! Also observe your general CUBE handbook! Cube_EPO_Umschlag_DE-EN_2011-04.indd 1 11.05.
Cube_EPO_Umschlag_DE-EN_2011-04.indd 2 11.05.
CUBE EPO Pedelec 12 13 14 15 16 17 1 2 6 3 3 1 4 5 6 7 8 9 10 11 Cube_EPO_Umschlag_DE-EN_2011-04.indd 3 5 4 18 2 19 20 21 22 23 24 25 26 27 28 11.05.
Display / Bedienelement Display / Control Element Display: Pulsanzeige / Heartrate indicator Geschwindigkeitsanzeige Speedometer Ladezustandsanzeige State of charge display Anzeige aktuelle Daten Indicator current data Anzeige Unterstützungsstufen Indicator assistance levels Bedienelement: Control element: O-Taste / O-button M-Taste / M-button U-Taste / U-button Cube_EPO_Umschlag_DE-EN_2011-04.indd 4 11.05.
Notizen Cube_EPO_Umschlag_DE-EN_2011-04.indd 5 11.05.
Pending System GmbH & Co. KG Ludwig-Hüttner-Str. 5-7 D-95679 Waldershof website@cube.eu www.cube.eu Cube_EPO_Umschlag_DE-EN_2011-04.indd 6 11.05.
1 Table of Contents Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Some Notes on these Supplementary Instructions. . . . . . . . . . . . . . 5 Intended Use. . . . . . . . . . . . . . .
2 Dear Customer, Even a manual as big as an encyclopaedia could not describe any possible combination of bicycle models and components or parts on the market. It therefore focuses on your newly purchased CUBE EPO pedelec and standard components and provides useful information and warnings. In purchasing this CUBE EPO pedelec you have chosen a product of high quality and technology. Each component of your new CUBE EPO pedelec has been designed, manufactured and assembled with great care and expertise.
3 Observe the legal regulations concerning off-road cycling. These regulations may differ in each country. Please respect nature when riding off-road. Only use your bicycle on signposted, well maintained trails and hard-surface roads. Before you set off, let us point out a few things that are very important to every cyclist: Never ride without a properly adjusted helmet and without glasses and take care to always wear suitable clothing.
4 Components Frame 1 Top tube 2 Down tube 3 Seat tube 4 Chainstay 5 Rear stay 6 Head tube 1 2 3 4 12 13 14 15 16 17 18 19 20 21 22 Saddle Seat post with integrated battery Seat post clamp Rotor rear Stem Handlebars Display Control element Shift lever Brake lever Headset Fork Rotor Brake front Drop-out Wheel 23 Quick-release 24 Spoke 25 Rim 26 Tyre 27 Valve 28 Hub Drive 5 Motor 6 Cassette sprockets 7 Rear derailleur 8 Chain 9 Chainring 10 Crank 11 Pedal a b c CUBE EPO Pedelec 12 13 14 15 16 17 1 2
5 Some Notes on these Supplementary Instructions These operating instructions are not intended to help you assemble a CUBE EPO pedelec from individual components, to repair it or to make partly assembled CUBE EPO pedelecs ready-for-use! The diagram shows a CUBE EPO pedelec. These supplementary instructions are not applicable to any other than the displayed bicycle type.
6 Intended Use 2. Speed pedelecs or S-pedelecs are bicycles with auxiliary motor that provides assistance to the rider even beyond speeds of 25 kph/15 mph. Keep in mind that every bicycle type is built for a specific intended use. Be sure to use your CUBE EPO pedelec only according to its intended use, as it may otherwise not withstand the stress, fail and cause an accident with unforeseeable consequences! Using it for another than the intended use will also void the warranty.
7 Before Your First Ride 3. The rechargeable battery of your CUBE EPO pedelec (e) must be charged before you set off for the first time. Are you familiar with the handling and mounting of the rechargeable battery (f)? Before you set off for the first time, check whether the battery is properly mounted, that it has engaged audibly and that it is locked (g). For more information see chapter “Rechargeable Battery”. 1. The CUBE EPO pedelec is designed for a maximum overall weight of 140 kg.
8 7. Are both saddle and handlebars properly adjusted? The saddle should be set to a height from which you can just reach the pedal in its lowest position with your heel. Check whether your toes reach to the floor when you are sitting on the saddle (d). Your CUBE dealer will be pleased to help you, if you are not happy with your seating position. For more information see chapter “Adjusting and using your bike” of your general CUBE handbook.
9 For more information see chapters “Check suspension fork” and “Adjusting and using your bike” of your general CUBE handbook. Further instructions regarding suspension forks are possibly enclosed with these supplementary instructions. note that in wet conditions the brake performance g Please is less effective and the tyre grip reduced. Keep this fact in mind in particular when riding on a wet road and do not ride as fast as you would in dry conditions.
10 BEFORE EVERY RIDE 3. Is your battery fully charged? Keep in mind to entirely recharge the battery after every ride. You should not wait until the battery is empty! Your CUBE EPO pedelec has undergone numerous tests during production and a final check has been carried out by your CUBE dealer.
11 With disc brakes (g) you should directly get a positive braking response. If you have to actuate the brake lever more than once to get a positive braking response, have the CUBE EPO pedelec checked by your CUBE dealer. 6. Are the tyres in good condition and do they have sufficient pressure? The minimum and maximum pressure (in bar or PSI) is indicated on the tyre side (e). For more information see chapter “Check the wheels” of your general CUBE handbook and the enclosed operating instructions.
12 closed quick-releases and other fastenings can g Improperly cause components of the CUBE EPO pedelec to come loose and result in serious accidents! A lighting set (a) that corresponds to the regulations is a must on public roads. Turn on the lights as soon as dusk sets in. For more information see chapter “Check lighting system” of your general CUBE handbook (b).
13 After an Accident 2. Check that handlebars and stem are neither bent nor broken and that they are level and upright. Make sure the stem is firmly fixed on the fork by trying to turn the handlebars relative to the front wheel (f). Briefly lean on the brake levers to make sure the handlebars are firmly fixed in the stem. 1. Check whether the wheels are still firmly fixed in the drop-outs (e) and whether the rims are still centred with respect to the frame or fork.
14 For more information see chapter “How to Use the Pinhead®Locking System” as well as chapters “Using your bike” and “Operate the quick-release action” of your general CUBE handbook and the enclosed operating instructions. 3. Check whether the chain still runs on the chainrings and the sprockets. If your CUBE EPO pedelec fell over to the chain side, verify the proper functioning of the gears (a). Ask somebody to lift the CUBE EPO pedelec by the saddle and carefully shift through all the gears.
15 7. Check whether the values shown on the display are correct and complete (f). Do not use your CUBE EPO pedelec, if the display shows an error message or a warning. Back home you need to check your CUBE EPO pedelec thoroughly. The damaged parts must be repaired. Ask your CUBE dealer for help. Do not set off on your CUBE EPO pedelec when the display shows a warning. In such a case, contact your CUBE dealer immediately.
16 How to Use the Pinhead®-Locking System How to Fasten Components Securely with a Pinhead®-Locking System For easy adjusting or mounting and dismounting the rechargeable battery or the seat post (a) and the wheels (b+c) of your CUBE EPO pedelec are fitted with a so-called Pinhead®-locking system. At the same time the Pinhead®-locking system provides reliable theft protection for these components. The Pinhead®-locking system should be handled with greatest attention, as it directly affects your safety.
17 Riding a CUBE EPO Pedelec – Special Features Range Your CUBE EPO pedelec is designed to be used like a conventional bicycle. The unique riding experience, however, starts when you actuate the drive system. At that moment the assistance generated by the 250 W motor in the rear wheel hub increases the stronger you pedal. How long and how far you can benefit from the auxiliary drive depends on several factors, i.e.
18 a test ride to make yourself familiar with the riding g Do characteristics of your CUBE EPO pedelec and the possibly higher speed and acceleration, before riding on public note that car drivers and other road users may ung Please derestimate your speed. Therefore, always ride on public roads with this fact in mind and anticipate the actions of not step on the pedals before sitting in the saddle and g Do Be ready to select the lowest drive assistance “ECO” brake at any time when you set off .
19 Riding without Drive Assistance Observe the following points when riding without rechargeable battery: Your CUBE EPO pedelec is designed to be also used without drive assistance, i.e. like a conventional bicycle. • Switch on the display of your CUBE EPO pedelec, even when riding without drive assistance; the functions of your cycle computer are only then available.
20 Display Operation and Control Inserting the Battery (a) Open the cover on the rear side of the display by using a coin and turning it to the left. Insert the battery (type 2032, 3V) with the “+“ mark showing to the top. Subsequently, reclose the cover by turning the coin to the right. Switch on the unit by pressing the AC-button on the rear side with a pointed object. Please unfold the cover of these supplementary instructions.
21 Settings Menue Odometer Press the M-button for more than 3 seconds to access the settings menu. Heart Rate Upper and Lower Limit Wheel Size User Data Settings – General Information In the settings menu, proceed as follows to change the individual settings. Clock Time Cube_EPO_Gesamt_EN_2011-05.indd 21 11.05.
22 Pairing and Searching Functions Before you use your CUBE EPO pedelec system for the first time, the sensors must be paired once with the display. Make sure all sensors are in direct vicinity and activated. Press the ON-button that is on the housing of the rechargeable battery for 5 seconds. In the case of the down tube and pannier rack option the four LEDs should blink alternately. The rechargeable battery is now for 60 seconds in the pairing mode.
23 Operating the Levels of Assistance Further Display Functions The CUBE EPO pedelec assistance is switched on by pressing the top O-button at the control element (Power button). It starts with the Eco level and can be switched through to the Power level by pressing O-button (e). Reset To reset the daily data press the U-button for 4 seconds. The display is completely reset by pressing the AC-button (g+h) (with a pointed object) on the bottom side of the display.
24 Rechargeable Battery • After 7 minutes of non-operation: The speed sensor changes into the sleep mode. You can wake up the sensor with a magnet. • After 20 minutes of non-operation: The display changes into the sleep mode. You can wake up the display by pressing any button on the display. • After 8 days of non-operation: The rechargeable battery changes into the deep-sleep mode. In this mode the battery’s self-discharge is reduced to a minimum. In this mode the rechargeable battery can be stored.
25 A A The lithium ion battery should be charged in an ambient temperature between 5 and 40 degrees Celsius (35 to 104 degrees Fahrenheit). Do not charge the lithioum ion battery in temperatures of 5 degrees Celsius below zero (23 degrees Fahrenheit) and over 60 degrees Celsius (140 degrees Fahrenheit). A A The charger (f) must only be connected to a usual 110 or 220 V socket.
26 A A Do not try to rebuild or disassemble the charger. Seat Post Option Do not use further a rechargeable battery with damaged housing or a damaged charger (mains plug, housing, cable) (a). Removing the Rechargeable Battery Before removing the seat post battery, make sure the magnetic connector is no longer connected to the charging socket of the rechargeable battery (b). You can disconnect the magnetic connector that leads from the drive to the battery with a slight jolt.
27 A A Be aware of possible grease or assembly paste residues on the seat post of your CUBE EPO pedelec. Make sure not to soil yourself and your clothes, when removing the rechargeable battery. Tighten the Pinhead®-locking system at the seat post of your CUBE EPO pedelec. Connect the magnetic connector to the charging socket of the rechargeable battery at the bottom bracket.
28 Pannier Rack Option With the rechargeable battery engaged with the pannier rack you can close the lock. The key is not necessary to close the lock. Apply a little pressure to press the projecting locking cyclinder into the lock until it engages, the battery being thus locked. Your CUBE EPO pedelec is now ready for use. Removing the Rechargeable Battery The pannier rack battery is double secured.
29 Down-Tube Option Press the rechargeable battery with a slight jolt in tilted position downwards (g) so that it engages with the fastening rail. Check the correct seat of the rechargeable battery on the fastening rail by closing the lock. The key is not necessary to close the lock. Apply a little pressure to press the projecting locking cyclinder into the lock until it engages, the battery being thus locked.
30 Charging the Rechargeable Battery For more details in this regard also read chapter “Technical Specifications“. If you have any questions, contact your CUBE dealer. You need not necessarily remove the rechargeable battery from your CUBE EPO pedelec to charge it. You can charge the rechargeable battery directly on the CUBE EPO pedelec (a) or remove the rechargeable battery by opening the lock or the Pinhead®-locking system (b) and charge it in your home or garage.
31 • The rechargeable battery has reached its maximum capacity after about five discharge-charge cycles. • The rechargeable battery and the charger (g) are compatible. Don’t use another charger and another rechargeable battery or any supposed replacement units! • The rechargeable battery reaches its maximum service life, when charged with an ambient temperature between +10 and +30 degrees Celsius (50 and 86 degrees Fahrenheit). • The battery can be charged in any state of charge.
32 Do not charge any other electrical devices with the supg plied charger of your CUBE EPO pedelec! When you remove your seat post battery for charging it A from the seat post with your CUBE EPO pedelec left in the open during the charging process, you shold protect the A (a) seat tube e.g. with a plastic bag against rain, water, moisture and dirt (b). A If the rechargeable battery or the charger (or parts of it) must be replaced, only use original spare parts. Contact your CUBE dealer.
33 Battery Care The CUBE EPO Pedelec – Special Features Storing the Rechargeable Battery Remove the rechargeable battery (e), if you do not use the CUBE EPO pedelec for a longer period of time (e.g. during the winter season). Store the rechargeable battery in a dry room at temperatures between 5 and 20 degrees Celsius (41 and 68 degrees Fahrenheit). The state of charge should be 50 to 70 % of the charging capacity (equal 5 to 7 bars on the state of charge display on your display).
34 Wheels and Tyre Equipment – Tyre Puncture (rear) And there is no need to calibrate the measuring sensors after remounting the rear wheel. All torque measuring sensors are in the drive housing and accordingly protected against external influences. For detailed information about repairing a puncture see chapter “Wheels and tyres” of your your general CUBE handbook. Besides your Pinhead®-key you only need a replacement tube (a) or a puncture kit, two tyre levers and a pump (b).
35 Tyre Wear Wheel Mounting Mounting the wheel is done in the reverse order of dismounting. Make sure the wheel axle slides snugly with its surfaces into the drop-outs (e) without getting jammed. Tighten the Pinhead®-locking system (see chapter “How to Use the Pinhead®-Locking System”). Due to higher driving forces the tyre of the rear wheel can wear down faster than with a conventional bicycle. Therefore, check the tread depth regularly and replace a worn tyre in time.
36 Transport of the CUBE EPO Pedelec By Car A Make sure to remove all movable and loose parts and above all the rechargeable battery and the display from your CUBE EPO pedelec before transporting it inside or outside the car. When you remove your seat post battery from the seat post for transporting your CUBE EPO pedelec on the roof of a car, you shold protect the seat tube e.g. with a plastic bag against rain, water, moisture and dirt.
37 By Train / By Public Transport you start your trip inform yourself in time about the i Before conditions of carriage and also observe the regulations and rules about bicycle transport in the countries through CUBE EPO pedelecs (e+f) can be transported like conventional bicycles by public transport. which you intend to travel. In the cities the regulations for taking bicycles or pedelecs by public transport differ. There are e.g.
38 TroubleShooting During the Charging Process In case of malfunctions during the charging process, carry out the following checks: • Is the mains cable properly connected and is there power in the socket? During the Ride • Are the contacts of the charger and the rechargeable battery clean and sound or are they bent? • Is the rechargeable battery damaged or defective? • Is the connector of the charger firm in the connection socket of the rechargeable battery? • If charging is still impossible, have the rec
39 Error Check Troubleshooting 1 No values on the display. Display battery empty? Replace display battery (CR2032). Re-pairing display, speed sensor and rechargeable battery (see chapter “Pairing and Search”). 2 Command selection doesn’t work with control element. Are buttons on control element operable? Contact your CUBE dealer. 3 Battery’s state of charge not visible on display. 1. Rechargeable battery and display are not paired. Carry out pairing a. Also wake up speed sensor with magnet.
40 Servicing and Maintenance If your bicycle does harder service, because you ride a great deal on poor road surfaces, it will require correspondingly shorter service periods. The off-season during the winter months is a very good time to take your CUBE EPO pedelec to your CUBE dealer for the annual inspection, as they will have plenty of time for you and for servicing. Your CUBE dealer will have assembled and adjusted your CUBE EPO pedelec ready for use when you come to collect it.
41 Maintenance and Care of the Drive If used appropriately and carefully, the electric drive (f) is maintenance-free. Service routines at the drive of your CUBE EPO pedelec must be carried out by a CUBE dealer. Safety services should be carried out by a CUBE dealer every 500 kilometres (310 miles).
42 Technical Specifications Normal charger (included in scope of delivery): • charging current: 2amp • charging time: 3.5 to 4 hours Drive Rapid charger (special equipment): Continuous rated power (statutory): 250 Watt Torque at drive: 40 Nm maximum to 10 Nm nominal Nominal voltage: 36 Volt Number of (full) charge cycles: 1,000 Operating and storage temperature: Charging: • min. 0 to max.
43 Warranty and guarantee Please observe the checks and routines that may be listed in the manuals supplied or the replacement of safety-relevant components, such as handlebars, brakes etc, if necessary. Your CUBE EPO pedelec was manufactured with care. Normally it is delivered to you by your CUBE dealer fully mounted. in mind that retrofitted accessories can impair the g Keep functioning of your CUBE EPO pedelec.
44 A Note on Wear This concerns: Some components of your CUBE EPO pedelec are subject to wear due to their function. The rate of wear will depend on care and maintenance and the way you use your CUBE EPO pedelec (mileage, riding in the rain, dirt, salt etc.). CUBE EPO pedelecs that are often left standing in the open may also be subject to increased wear through weathering.
