User guide

Battery Pack and Charger
119
1b. Disconnect the battery pack’s positive lead from
the contactor assembly using a 7/16” wrench.
See Figure 6.6.
2. Disconnect the seat switch.
3. Remove the two nuts that secure the seat bracket to
the mower using a 1/2” wrench.
See Figure 6.8.
4. Lift the seat and seat bracket off of the mower.
Figure 6.6
Contactor assembly
Positive lead
Figure 6.7
positive lead
! CAUTION! CAUTION
The battery pack’s positive lead is
still hot. Take measures, such as
taping up the cable lug with electri-
cal tape or a plastic bag, to prevent the cable
end from making contact with any metal sur-
face on the mower. See Figure 6.7.
Figure 6.8
Nuts
