Safe Operation Practices • Set-Up • Operation • Maintenance • Troubleshooting • Warranty Operator’s Manual 547 cc EFI OHV Vertical Shaft Engine WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS ENGINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No.
1 To The Owner Thank You This Operator’s Manual is an important part of your new engine. It will help you prepare and maintain the engine for the best performance. Please read and understand the contents before operating the engine. Table of Contents Important Safe Operation Practices...................... 3 Safety Labels............................................................. 5 Set-Up........................................................................ 6 Controls & Features.......................
Important Safe Operation Practices 2 WARNING! This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate the equipment. Failure to comply with these instructions may result in personal injury. When you see this symbol.
7. 4 Do not overfill fuel tank. Fill tank to full as indicated by the fuel level indicator installed inside of the fuel tank or marked on the tank. Do not over-fill to allow space for fuel expansion. On some models, a fuel level indicator may NOT be present, in this instance, fill the tank no more than 1/2 inch below the bottom of the filler neck to allow space for fuel expansion. 8. Replace fuel cap and tighten until the cap ratchets. 9.
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate. WARNING—GASOLINE IS FLAMMABLE Allow the engine to cool at least two minutes before refueling.
3 Set-Up Gas & Oil Checking Oil Level NOTE: The engine is shipped without gasoline and with motor oil in the engine. However, you MUST check the oil level before operating. Be careful not to overfill. Running the engine with insufficient oil can cause serious engine damage and void the engine warranty. NOTE: Be sure to check the oil while on a level surface with the engine stopped. WARNING! Always keep hands and feet clear of 1. Remove the oil filler cap/dipstick and wipe the dipstick clean. 2.
Fuel Requirements Adding Fuel WARNING! An adult should fuel this engine. NEVER allow children to refuel the engine. Gasoline (fuel) vapors are highly flammable and can explode. Fuel vapors can spread and be ignited by a spark or flame many feet away from engine.
4 Controls and Features Finger Guard Air Cleaner Spark Plug Throttle Body Assembly Oil Filter Oil Fill Cap Electric Starter Oil Drain Figure 4-1 Throttle Control Oil Fill Cap The throttle control is located on the mower and is used to aid in starting/stopping the engine and adjusting engine speeds. Refer to the Controls and Features section of the equipment manual for more information regarding this control. Remove the oil fill cap to check the oil level and add oil.
5 Operation Pre-Operation Check Rotary Key Switch Start The engine is shipped without gasoline and with oil in the engine. See the Set-Up Section of this manual for instructions on adding gasoline and checking oil. Run Position Stop Position Starting Engine Start Position Rotary Key Switch Start 1. Place the PTO in the DISENGAGED (OFF) position. 2. Fully engage the tractor’s brake. 3. Move the throttle into the FAST position. 4. Insert the key into the ignition switch. 5.
6 Engine Maintenance WARNING: Shut off the engine before performing any maintenance. To prevent accidental start-up, disconnect the spark plug boot. Periodic inspection and adjustment of the engine is essential if high level performance is to be maintained. Regular maintenance will also ensure a long service life. The required service intervals and the kind of maintenance to be performed are described in the table below. Follow the hourly or calendar intervals, whichever occur first.
Oil Service Replace Oil Filter • Check oil level regularly. • Be sure correct oil level is maintained. Check every five to ten hours before starting engine. See oil checking procedure in the Set-Up section. This engine is equipped with a spin-on oil filter that should be replaced each time an oil change is performed, every season or 100 hours. Refer to Figure 6-2. Oil Drain IMPORTANT: Be sure to check engine on a level surface with the engine stopped.
Add Oil 2. Remove the air filter cover. See Figure 6-4. IMPORTANT: Be sure to check engine on a level surface with the engine stopped. 1. Wipe around dipstick cap and tube with a clean cloth to remove any debris. See Figure 6-3. 1 Thumb Screw 2 Air Filter Cover Figure 6-4 3. Pull up on an angle and then forward to remove the air filter. See Figure 6-5. Figure 6-3 2. Remove dipstick and wipe clean with a cloth. 3. Pour oil into the dipstick tube. Do not over fill.
NOTE: The foam element cannot be purchased separately. Air filter is only sold as an assembly. Air Filter Cover Pre-Filter 1 Air FIlter 2 Figure 6-8 Figure 6-6 5. 6. To clean foam element, wash in a mild liquid detergent and water. Squeeze or press the foam element to rinse out dirt and water. Do not twist; this could damage or tear the foam element. Allow to dry thoroughly before using. DO NOT oil the foam element.
3. WARNING: Accumulation of debris around muffler could cause a fire. Inspect and clean before every use. Measure the plug gap with a feeler gauge. Correct as necessary by bending electrode. See Figure 6-10. The gap should be set to 0.024-0.031 in. Storage Electrode CAUTION: Failure to use a fuel stabilizing additive before off-season storage may result in damage to your engine’s carburetor. Subsequent damage would not be covered under the manufacturer’s warranty. 0.024-0.031 in. Figure 6-10 4. 5.
7 Troubleshooting Problem Engine Fails to start Cause Remedy 1. Spark plug boot disconnected. 1. Connect wire to spark boot. 2. Fuel tank empty or stale fuel. 2. Fill tank with clean, fresh gasoline. 3. Faulty spark plug. 3. Clean, adjust gap, or replace. 4. Engine flooded. 4. Crank engine with throttle in FAST position. 5. Dead battery. 5. Recharge battery. See equipment operator’s manual. 6. Blown fuse. 6. Replace blown fuse. See equipment operator’s manual. 1. Spark plug boot loose. 1.
8 Replacement Parts Component Part Number and Description 951-10292 Spark Plug 937-05066 Air Filter Assembly (Includes Pre-Filter) 951-12690 Oil Filter Phone (800) 800-7310 or (330) 220-4683 to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.mtdproducts.com.
FEDERAL and/or CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS MTD Consumer Group Inc, the United States Environmental Protection Agency (EPA), and for those products certified for sale in the state of California, the California Air Resources Board (CARB) are pleased to explain the emission control system (ECS) warranty on your 20152016 small off-road spark-ignited engine and equipment (outdoor equipment).
10. Add-on or modified parts that are not exempted by the Air Resources Board may not be used. The use of any non-exempted add-on or modified parts by the ultimate purchaser will be grounds for disallowing a warranty claim. MTD Consumer Group Inc will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
Medidas importantes de seguridad • Configuración • Funcionamiento • Mantenimiento • Solución de problemas • Garantía Manual del Operador Motor de 547 cc EFI con eje vertical y válvulas en cabeza ADVERTENCIA LEA Y RESPETE TODAS LAS NORMAS DE SEGURIDAD E INSTRUCCIONES INCLUIDAS EN ESTE MANUAL ANTES DE PONER EN FUNCIONAMIENTO ESTA MOTOR. SI NO RESPETA ESTAS INSTRUCCIONES PUEDE PROVOCAR LESIONES PERSONALES. MTD LLC.
1 Al propietario Gracias Este Manual del Operador es una parte importante de su nuevo motor. Le ayudará a preparar y mantener la unidad para obtener los mejores resultados. Antes de operar el motor lea cuidadosamente y comprenda todo el manual. Índice Medidas importantes de seguridad....................... 3 Configuración........................................................... 6 Controles y Características...................................... 8 Funcionamiento..........................................
2 Medidas importantes de seguridad ¡ADVERTENCIA! La presencia de este símbolo indica que se trata de instrucciones de seguridad importantes que debe respetar para evitar poner en riesgo su seguridad personal y/o material y la de los demás. Lea y siga todas las instrucciones de este manual antes de poner en funcionamiento este equipo. Si no respeta estas instrucciones puede provocar lesiones personales. Cuando vea este símbolo. TENGA EN CUENTA LA ADVERTENCIA.
7. No llene demasiado el tanque de combustible. Llene el tanque completo indicado por el indicador de nivel de combustible instalado en el interior del depósito de combustible o marcado en el depósito. No más de relleno para dejar espacio para la expansión del combustible.
Símbolos De Seguridad Esta página representa y describe la seguridad los símbolos que pueden parecer en este producto. Lea, comprenda, y siga todas instrucciones en la máquina antes procurar para reunir y operar. Símbolo Descripción LEA EL MANUAL(S) DEL OPERADOR Lea, comprenda, y siga todas instrucciones en el manual (manuales) antes procurar para reunir y operar. ADVERTENCIA— GASOLINA ES INFLAMABLE Allow the engine to cool at least two minutes before refueling.
3 Configuración Gasolina y aceite NOTA: El motor se envía sin gasolina y con aceite en el motor. Sin embargo, usted debe comprobar el nivel de aceite antes de operar. Tenga cuidado de no llenar en exceso. Hacer funcionar el motor sin suficiente aceite puede causarle graves daños y anula la garantía del motor. ¡ADVERTENCIA! Siempre mantenga las manos y los pies alejados de las piezas móviles del equipo. No utilice fluidos comprimidos para arrancar. Los vapores son inflamables.
Requisitos sobre el combustible Carga de combustible ADVERTENCIA! Un adulto debe de combustible de este motor. NUNCA permita que los niños para abastecerse de combustible del motor tis. La gasolina (combustible) vapores son altamente inflamables y pueden explotar. Los vapores del combustible puede extenderse y ser encendida por una chispa o llama muchos metros de distancia del motor.
4 Controles y Características Dedo de la Guardia Depurador de aire Bujía de encendido Conjunto del cuerpo del acelerador Filtro de aceite Tapa del aceite Arranque eléctrico Tubo de drenaje Figura 4-1 Control del acelerador Tapa del aceite Control del acelerador se encuentra en la cortadora de césped y se utiliza para ayudar a arrancar / parar el motor y el ajuste de las velocidades del motor.
5 Funcionamiento Control previo al funcionamiento Key Rotary interruptor de arranque El motor se envía sin gasolina y con aceite en el motor. Consulte la Sección Configuración incluida en este manual para ver las instrucciones para la carga de gasolina y comprobación del aceite. Posición de funcionamiento Posición de detención Encendido del motor Posición de encendido Key Rotary interruptor de arranque 1. 2. 3. 4. 5. Coloque la toma de fuerza en la posición OFF (desconectada).
6 Mantenimiento y Adjustes ADVERTENCIA: Apague el motor antes de realizar el mantenimiento. Para evitar una puesta en marcha accidental, desconecte la funda de la bujía. IMPORTANTE: Si el motor debe inclinarse para transportar equipo o para inspeccionar o extraer pasto, mantenga el lado de la bujía del motor hacia arriba. Si la bujía del motor se transporta o se inclina hacia abajo puede causar humo, un arranque difícil, contaminación de la bujía o saturación con aceite del depurador de aire.
Mantenimiento del aceite • Inspeccione el nivel de aceite regularmente. • Asegúrese de que se mantenga el nivel de aceite correcto. Inspeccione cada cinco a diez horas antes de poner en marcha el motor. Vea el procedimiento de verificación del nivel de aceite en la sección Configuración. De drenaje de aceite IMPORTANTE: Asegúrese de inspeccionar el motor sobre una superficie nivelada y con el motor apagado. Drene el aceite mientras el motor esté caliente para asegurar un drenaje rápido y completo. 1.
Añadir aceite 1. Destornillar y retire los pernos de mariposa. IMPORTANTE: Asegúrese de revisar el motor en una superficie plana con el motor parado. 2. Retire la cubierta del depurador de aire. Vea la Figura 6-4. 1. Limpie alrededor del tapón de la varilla y el tubo con un paño limpio para eliminar los residuos. Véa la Figura 6-3. 1 Perno de mariposa Cubierta del depurador de aire 2 Figura 6-4 3. Tire hacia arriba en un ángulo y luego remitir a quitar el filtro de aire. Vea la Figura 6-5.
4. Quitar la espuma pre-filtro de aire de todo el papel de filtro. Vea la Figura 6-6. Sustituya el elemento de papel cuando sucio o dañado. Limpia el elemento de espuma o sustituya cuando dañado. 7. Coloque la tapa del filtro de aire. Vea la Figura 6-8. Gire tornillos en sentido horario hasta que quede ajustado. Revise si hay desalineación. Tapa del filtro de aire NOTA: El elemento de espuma no puede ser comprado por separado. Filtro de aire sólo se vende como un conjunto.
ADVERTENCIA: Si el motor ha estado funcionando, el silenciador estará muy caliente. Tenga cuidado de no tocar el silenciador. 2. Inspeccione visualmente la bujía. Elimine la bujía si presenta mucho desgaste, o si el aislante está agrietado o astillado. Limpie la bujía con un cepillo de alambre si se va a reutilizar. 3. Mida la separación de bujía con un calibrador. Corrija de ser necesario torciendo el electrodo lateral. Vea la Figura 6-10. La separación debe establecerse en 0,024-0,031 pulg.
Almacenamiento PRECAUCIÓN: El no usar un aditivo estabilizador de combustible antes de guardarlo fuera de temporada puede resultar en daños al carburador de su motor. Daños posteriores no estarían cubiertos por la garantía del fabricante. La gasolina que se almacenan más de 30 días tiene que ser pretratada después de la compra con estabilizador de combustible para prevenir la goma y el barniz se formen en el combustible y sistema de admisión de motores.
7 Solución de Problemas Problema El motor no arranca Solución 1. Alambre de bujía desconectado. 1. Unir el alambre a la bujía. 2. Depósito de combustible combustible vacío o añejo. 2. Llenar el tanque de la gasolina limpia, fresca. 3. Bujía defectuosa. 3. Limpio, ajuste el hueco, o sustituir. 4. Se ahogó el motor. 4. Arranque el motor con el regulador en posición FAST (velocidad rápida). 5. Sin batería. 5. Recargue la batería. 6. Fusible quemado. 6. Cambie el fusible quemado. 1.
DECLARACIÓN FEDERAL y/o DE CALIFORNIA SOBRE GARANTÍAS EN EL CONTROL DE EMISIONES SUS DERECHOS Y OBLIGACIONES EN CUANTO A LA GARANTÍA MTD Consumer Group Inc, la Agencia de Protección Medioambiental de los Estados Unidos (EPA), y para aquellos productos certificados para su venta en el estado de California, el Departamento de los Recursos del Aire de California (CARB) se complacen en explicar la garantía que cubre al sistema de control (ECS) de emisiones de su equipo y motor (equipos de exteriores) de encendi
7. MTD Consumer Group Inc es responsable por daños causados a otros componentes de motores o equipos derivados de la falla bajo garantía de cualquier pieza garantizada. 8. Durante la totalidad del período de garantía del motor y equipo para todo terreno arriba mencionado, MTD Consumer Group Inc mantendrá un suministro de piezas bajo garantía suficiente para satisfacer la demanda esperada de tales piezas. 9.
