User Manual
Table Of Contents
- SECTION 1: important safe operation practices
- SECTION 2: slope gauge
- SECTION 3: tractor set-up
- Gas and Oil Fill-up
- Setting the Gauge Wheels and Roller
- SECTION 4: know your lawn tractor
- Throttle Control Lever
- Choke Control
- Brake Pedal
- Seat Adjustment Lever
- Ignition Switch Module
- Drive Pedal
- Systems Indicator Monitor / Hour Meter
- Deck Lift Lever
- Electric PTO / Blade Engage Knob
- Cruise Control Lever
- Parking Brake Lever
- SECTION 5: operating your lawn tractor
- Safety Interlock Switches
- Reverse Caution Mode
- Starting the Engine
- Stopping the Engine
- Engaging the Parking Brake
- Driving The Tractor
- Driving On Slopes
- Setting The Cruise Control
- Using the Deck Lift Lever
- Operating the Headlights
- Moving The Tractor Manually
- Engaging the PTO
- Mowing
- SECTION 6: making adjustments
- Leveling the Deck
- Parking Brake Adjustment
- Seat Adjustment
- Steering Adjustment
- SECTION 7: maintaining your lawn tractor
- Engine
- Changing the Engine OIl
- Air Filter
- Cleaning the Engine And Deck
- Lubrication
- Carburetor
- SECTION 8: service
- Tires
- Fuse
- Cutting Blades
- Battery
- Cutting Deck Removal
- Changing the Deck Belt
- Changing The Transmission Drive Belt
- Hydrostatic Transmission
- SECTION 9: off-season storage
- Engine
- SECTION 10: maintenance chart
- SECTION 11: maintenance log
- SECTION 12: troubleshooting
- SECTION 13: attachments & accessories
- SECTION 14: Replacement Parts
- SECTION 15: specifications*
31
SECTION 13: ATTACHMENTS & ACCESSORIES
The following attachments and accessories are compatible for Series 1500 Garden Tractors. See your Cub Cadet
dealer or the retailer from which you purchased your tractor for information regarding price and availability.
† 190-824 is required for use of this attachment.
Attachments
19A-102 16 cu. ft. Steel Tow Cart
19A-103 42" Tow-Behind Sweeper
19A-104 25 gal. Tow-Behind Sprayer
19A-105 Tow-Behind Broadcast Spreader
19A-106 10 cu. ft. Poly Tow Cart
19A-107 48" Tow-Behind Dethacher
19A-108 48" Tow-Behind Plug Aerator
19A-109 48" Tow-Behind Spike Aerator
19A-110 48" Tow-Behind Aerator Spreader
19A-112 Box Scraper
19A-113 48" Push Lawn Roller (Does Not Attach to Tractor)
190-217B Mow-N-Vac Debris Collection System
190-425 17 cu. ft. Dump Cart
190-458 15 cu. ft. Dump Cart
190-653 10 cu. ft. Dump Cart
190-459 46-inch Lawn Sweeper
190-285 Triple Bagger Grass Collector (For 54-inch Decks)
190-032 42-inch Two-stage Snow Thrower
190-672 Front Bumper Kit
190-674 46-inch Front Dozer Blade
190-675 Rear Wheel Weight Set
190-824 Sleeve Hitch with Electric Lift
190-841 Mulch Kit (For 54-inch Decks)
Sleeve Hitch Attachments
190-825 30-inch Hydraulic Tiller†
190-978 10-inch Mulboard Plow†
190-980 Single-disc Harrow†
190-984 Row Crop Cultivator†
190-804 42-inch Heavy Duty Rear Blade†
