SECTION 9: OFF-SEASON STORAGE
Clean and lubricate the tractor as instructed in Section 7:
MAINTAINING YOUR LAWN TRACTOR on page 18 of this
manual before storing for an extended period.
Engine
If the engine will be out of service for two months or
more, use the following storage procedure:
• Clean the exterior surfaces of the engine.
• Change the oil and filter while the engine is still
warm from operation. Refer to Changing the Engine OIl
on page 19.
• The fuel system must be completely emptied, or the
gasoline must be treated with a fuel stabilizer such
as STA-BIL
®
to prevent deterioration. If you choose
to use a stabilizer, follow the manufacturers
recommendations, and add the correct amount for
the capacity of the fuel system. Fill the fuel tank with
clean, fresh gasoline. Run the engine for 2-3
minutes to get stabilized fuel into the carburetor.
To empty the system, run the engine until the tank
and system are empty.
WARNING: Drain fuel only into an
approved container outdoors, away from an
open flame. Allow engine to cool. Extinguish
cigarettes, cigars, pipes, and other sources of
ignition prior to draining fuel.
• Remove the spark plug. Add one tablespoon of
engine oil into the spark plug hole. Install the plug,
but do not reconnect the plug wire. Crank the
engine two or three revolutions.
• Store the engine in a clean, dry place.
WARNING: Never store the machine or
fuel container indoors where there is an open
flame, spark or pilot light such as on water
heater, furnace, clothes dryer or other gas
appliance.
SECTION 10: MAINTENANCE CHART
Before
Each Use
Every
10 Hours
Every
25 Hours
Every
50 Hours
Every
100 Hours
Prior
to Storing
Clean Hood/Dash Louvers
Check Engine Oil Level
Check Air Filter for dirty, loose
or damaged parts.
Clean and Re-oil Air Filter’s Foam
Precleaner
Replace Air Filter Element
Change Engine Oil
and Replace Oil Filter
Clean Battery Terminals
Lube Front Axles and Rims
Clean Engine Cooling Fins
Lube Front Deck Wheels
Lube Deck Spindles
Lube Pedal Pivot Points
Check Spark Plug Condition & Gap
Replace Fuel Filter
