User Manual

13
Starting the Engine
WARNING: Never operate the tractor if the
interlock system is malfunctioning. This
system was designed for your safety.
NOTE: Refer to the TRACTOR SET-UP on page 8 of this
manual for Gasoline and Oil fill-up instructions.
• Insert the tractor key into the ignition switch
module.
• Place the PTO (Blade Engage) knob in the
disengaged (OFF) position.
• Engage the tractor’s parking brake.
• Activate the choke control.
• Turn the ignition key clockwise to the START
position. After the engine starts, release the key. It
will return to the NORMAL MOWING position.
IMPORTANT: Do NOT hold the key in the START
position for longer than ten seconds at a time. Doing so
may cause damage to your engine’s electric starter.
• After the engine starts, deactivate the choke
control.
NOTE: Do NOT leave the choke control on while
operating the tractor. Doing so will result in a "rich" fuel
mixture and cause the engine to run poorly.
Stopping the Engine
WARNING: If you strike a foreign object,
stop the engine and disconnect the spark plug
wire(s). Thoroughly inspect the machine for
any damage. Repair the damage before
restarting and operating
• If the blades are engaged, place the PTO/Blade
Engage knob in the disengaged (OFF) position.
• Place the throttle control near the FAST position
• Turn the ignition key to the STOP position.
• Remove the key from the ignition switch to prevent
unintended starting.
Engaging the Parking Brake
To engage the parking brake:
• Fully depress the brake pedal and hold it while
gently pushing the parking brake lever downward.
• Hold the parking brake lever down while removing
your foot from the brake pedal.
• Once engaged, the parking brake lever and the
brake pedal will lock in the “down” position.
To disengage the parking brake:
• Slightly depress the brake pedal.
NOTE: The parking brake must be engaged if the
operator leaves the seat with the engine running or the
engine will automatically shut off.
Driving The Tractor
WARNING: Avoid sudden starts, ex-
cessive speed and sudden stops.
WARNING: Do not leave the seat of the
tractor without first placing the PTO/Blade
Engage knob in the disengaged (OFF)
position, depressing the brake pedal and
engaging the parking brake. If leaving the
tractor unattended, also turn the ignition key
off and remove the key.
• Briefly depress the brake pedal to release the
parking brake. Move the throttle lever into the FAST
(rabbit) position.
• To travel FORWARD, slowly depress the upper
portion of the drive pedal forward until the desired
speed is achieved. See Figure 5.
Figure 5
• To travel in REVERSE, check that the area behind
is clear then slowly depress the lower portion of the
drive pedal with the ball of your foot (NOT your
heel) until the desired speed is achieved. See
Figure 5.
IMPORTANT: Do NOT attempt to change the direction of
travel when the tractor is in motion. Always bring the
tractor to a complete stop before pivoting the drive
pedal from forward to reverse or vice versa.
Brake Pedal
Drive Pedal
