Illustrated Parts Manual Model CC30 Mini Rider CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No.
To The Owner Thank You Thank you for purchasing a Cub Cadet Lawn Tractor. It was carefully engineered to provide excellent performance when properly operated and maintained. All information in this manual is relative to the most recent product information available at the time of printing. Please be aware that this Illustrated Part’s Manual may cover a range of product specifications for various models. Components listed and/or illustrated in this manual may not be applicable to all models.
This page intentionally left blank.
Frame & Fender 18 19 15 25 18 13 4 21 20 3 4 1 27 8 16 10 14 23 9 24 22 28 11 29 8 2 17 14 6 17 8 7 8 12 5 26 9 8 4
Frame & Fender Ref. No. Part No. Description 1 710-05073 Screw, 1/4-20 x .500 2 710-04187A Screw, 1/4-15 x 0.50 3 731-08753A Running Board Plug 4 738-04184A Shoulder Screw, .368 X.113: 1/4-20 5 683-05015 Frame Assembly 6 683-05019 Column Assembly 7 710-06194 Hex Washer Screw, 5/16-18 x .75 8 710-1652 Tap Screw, 1/4-20, .
Drive System 16 29 12 9 7 35 31 34 30 34 32 3 38 21 44 6 33 43 41 40 42 39 19 25 22 23 8 15 36 26 14 37 5 17 28 45 13 20 18 1 2 24 10 48 46 4 47 50 49 6 11 27 11
Drive System Ref. No. Part No. Description Ref. No. Part No. Description 1 918-05056A Transmission Assembly 26 747-05593 Shift Rod 2 647-04262C Shift Handle Assembly 27 747-06126 Deck Belt Keeper, 30" 3 683-04768A Drive Assembly Idler 28 948-0334 Spacer 4 710-05339 Screw, 5/16-24 x .750 29 750-04456 Spacer, .260 X .372 X 1.420 5 710-04484 Tap Screw, 5/16-18, .750 30 750-05563 Spacer, .385 x .625 x .500 6 710-0599 Tap Scew, 1/4-20, 0.500 31 954-05040 V-Belt, 5L:35.
Seat, Fuel Tank & Electrical 7 8 6 3 2 4 14 5 1 26 29 28 27 20 12 19 10 33 32 25 11 32 34 31 23 31 18 21 30 15 16 24 22 17 13 13 17 17 13 8 9 17 13
Seat, Fuel Tank & Electrical Ref. No. Part No. Description 1 710-0607 Tap Screw, 5/16-18, 0.500 2 720-04009A Knob, 3/8-16, .875 3 712-04063 Flange Lock Nut, 5/16-18 4 732-04905 Seat Spring 5 938-0140 Shldr Spacer, .435 X .178-5/16 X .56 6 935-0199A Rubber Bumper, .63 Dia 7 757-05019 Seat 8 783-07213A Seat Pivot Bracket 9 710-0227 Screw, #8 10 710-04484 Tap Screw, 5/16-18, .750 11 710-1652 Tap Screw, 1/4-20, .
Front End Steering 28 18 7 27 3 17 15 4 10 6 16 19 14 21 21 12 20 26 8 25 13 10 23 11 24 30 9 10 5 29 8 12 30 12 2 12 1 5 14 21 21 22 29 9
Front End Steering Ref. No. Part No. Description 1 683-04726 Front Axle Assembly, RH 2 683-04727 Front Axle Assembly, LH 3 683-04761 Upper Tube Assembly 4 683-04762 Lower Tube Assembly 5 714-0162 Cotter Pin, 5/32 x 1.25 6 738-05000 Shoulder Screw, .375 x .148 x 1/4-20 7 710-0643 Hex Head Screw, 5/16-18:1.00 8 710-0703 Carriage Screw, 1/4-20, .
Pedal Controls 14 23 13 16 17 11 2 8 8 5 18 6 12 10 1 9 15 7 22 19 4 20 3 8 4 21 21 Ref. No. 12 Part No. Description Ref. No. Part No. Description 1 683-05017 Brake Pedal Assembly 13 747-06033A Brake Rod 2 910-0224 Screw, #10-16:0.500 14 732-0716D Extension Spring, .59 OD x 4.00 LG 3 710-0376 Hex Head Scerw, 5/16-18:1.00 15 735-04279 Foot Pad, 2.5" LG. 4 710-04484 Tap Screw, 5/16-18:.750 16 738-04184A Shoulder Screw, .368 X.
Deck Lift 19 6 21 14 3 15 3 11 1 12 13 18 15 11 5 12 15 2 17 8 10 12 9 20 16 4 7 Ref. No. 1 Part No. 683-05060 Description Ref. No. Part No. Description Lift Assembly Shaft 12 714-04043 Bow-Tie Cotter Pin, 91 720-0311 Grip Handle, 1/2 2 683-04757 Front Hanger Bracket Assembly 13 3 710-04484 Tap Screw, 5/16-18, .750 14 732-04692 Extension Spring, .85 OD X 5.915 LG 4 710-0514 Hex Head Screw, 3/8-16, 1.00 15 936-0300 Flat Washer, .406 X .875 X .
30” Deck 1 15 3 10 22 43 42 41 39 2 27 12 9 42 26 25 14 40 14 21 19 1 41 17 23 46 4 20 36 32 34 32 8 37 15 28 7 14 29 11 31 5 38 16 18 45 6 35 24 44 34 36 33 13 30
30” Deck Ref. Part Number Description Ref. Part Number Description 1 918-04822A Spindle Pulley Assembly, 6.3 DIA 24 738-05022 Shoulder Spacer, .134 x .500 x .438 2 631-05024 Deck Belt Cover 25 750-04456 Spacer, .260 X .372 X 1.420 LG 3 647-05028 Idler Rod Assembly 26 954-05001 V-Type Belt, 43.5 LG 4 983-05034 PTO Brake Assembly Bracket 27 756-04224 Flat Idler Pulley, 2.
Engine Accessories MTD P90 6 10 11 1 9 5 2 7 2 2 3 12 8 4 Ref. No. 16 Part No. Description 1 710-04483 Tap Screw, 1/4-20, 0.500 2 710-04683A Tap Screw, 3/8-16, 1.000 3 710-05446 Tap Screw, 3/8-16, 2.250 4 710-06067 Hex Head Screw, 7/16-20 x 1.25 5 912-0691 Nut, Hex Nylon Lock, M6-1.0 6 726-0205 Hose Clamp, .490 DIA. 7 731-1682A Oil Drain Sleeve 8 736-0322 Flat Washer, .450 x 1.25 x .164 9 946-04829A Throttle/Choke Cable 31 Lg.
Wiring Harness Schematic - 725-06042 17
Labels 777D19445 777D19446 777D16495 777S35300 420cc OH V OV ERHE AD VA LV E S35300 D16495 777X46971 777I23784 CC30 COMMON PARTSI TEM NUMBER Blade( s) 942-0438 5 Deck belt (s) 954- 0500 1 Driv e belt (s) 954- 0241A / 954- 04331 Spar k Plug (s) 951-10292 Air Filter 951-12260 Oil Filter 951-12690 Fuel Filter BS-298090S Amount of oil & weight 57 oz / 10W-30 X46971 COMMON PARTSI Battery Voltag e ACCESSORIESI Bagger Mulch Kit Riding Mower Cove r Oil Siphon Blade Removal Tool ww w.
Notes 19
Engine Model 4P90JUA Air Intake 120 121 122 121 126 124 127 128 127 130 129 Ref.
4P90JUA Engine Shroud 192 192 2 3 1 2 4 3 2 4 3 5 4 6 6 7 Ref. Part Number Description 1 751-12205 Debris Shield 2 712-04290 Nut 3 750-05320 Engine Shroud Spacer 4 710-05304 Starter / Shroud Stud M6×100 5 951-11622 Flexible Clamp 6 710-05305 Hook Bolt 7 951-12206 Air Shield 192 710-05303 Self-Tapping Bolt 5.
4P90JUA Crankcase 48 49 50 51 197 - Gasket Kit - Complete 52 198 - Gasket Kit - External 53 199 - Complete Engine 47 189 72 183 185 72 73 186 184 55 183 54 56 57 58 59 62 68 178 60 66 64 65 69 67 22 70 74 63
4P90JUA Crankcase Ref. Part Number Description Ref. Part Number Description 47 951-11499 Upper Crankshaft Seal 68 951-12234 Throttle Control Bracket 48 710-04916 Bolt M6×14 69 750-05530 Component Bracket Spacer 49 751-12770 Breather Cover Plate 70 951-12235 Breather Hose Assembly 50 951-12226 Breather Gasket 72 951-12236 Breather Hose Clamp 51 951-12685 Umbrella Valve 73 751-12200A Short Block Assembly 52 951-12227 Mesh Screen (Incl.
4P90JUA Cylinder Head 177 197 - Gasket Kit - Complete 198 - Gasket Kit - External 176 199 - Complete Engine 173 175 174 172 154 152 153 157 155 175 174 151 162 151 155 153 146 147 157 148 173 164 149 163 150 193 146 147 148 149 194 171 145 196 164 144 143 163 170 166 167 168 169 142 165 140 142 142 142 140 140 141 140 24
4P90JUA Cylinder Head Ref. Part Number Description Ref. 165 Part Number 951-12202 Description Cylinder Head Kit 140 710-05315 Bolt M5×10 141 951-12265 Cowl 142 710-05316 Valve Cover Bolt 166 751-12774 Air Valve Core 143 951-12266 Valve Cover 167 751-12775 Strainer Clip 144 951-12267 Valve Cover Ring Gasket 168 751-12776 Strainer 145 951-11981 Rocker Arm Assembly 169 751-12777 The Air Valve Bonnet 736-04629 Washer (Incl.
4P90JUA Crankshaft & Crankcase Cover 76 75 79 80 77 91 92 83 5 93 90 82 81 98 104 89 88 87 86 84 99 100 86 101 85 112 113 116 117 103 195 114 115 118 119 117 117 26 102
4P90JUA Crankshaft & Crankcase Cover Ref. Part Number Description Ref. Part Number Description 5 951-11622 Flexible Clamp 98 951-12248 Oil Pump Assembly 75 951-12238 Crankshaft Assembly 99 951-12247 O-Ring 10×2.65 76 951-11969 Main Bearing 100 951-12249 Filter 77 951-10307 Woodruff Key 101 951-12250 Filter Spring 79 951-12239 Dipstick Assembly 102 951-12251 O-Ring 35.5×2.
4P90JUA Carburetor Assembly 134 133 134 132 137 139 132 136 139 I J K L K H O 131 200 - Carburetor Kit - Major N S P T U V W X Y BB CC DD Z GG HH 28 B C D E Q R G M 138 A F EE FF AA
4P90JUA Carburetor Assembly Ref. Part Number Description Ref.
4P90JUA Muffler Assembly 191 191 191 191 48 190 161 161 159 160 158 Ref.
4P90JUA Starter Assembly 9 8 10 11 12 11 12 11 12 24 23 13 24 25 36 34 35 33 35 36 34 15 16 17 31 19 29 30 Part Number 37 18 28 Ref. 37 14 25 Description 21 30 Ref.
4P90JUA Ignition & Electrical 40 41 42 43 38 38 38 44 39 45 46 Ref. 32 Part Number Description 38 710-04920 Bolt M6×28 39 951-12220 Ignition Coil Assembly 40 712-04220 Flywheel Nut M16×1.5 41 951-12221 Fan Mounting Plate 42 751-12222A Cooling Fan 43 951-12223 Flywheel 44 951-12224 Coil Assy.
Notes 33
Engine Model 4P90JUB Air Intake 120 121 122 121 126 124 127 128 127 130 129 Ref.
4P90JUB Engine Shroud 192 192 2 3 1 2 4 3 2 4 3 5 4 6 6 7 Ref. Part Number Description 1 951-12205 Debris Shield 2 712-04290 Nut 3 750-05320 Engine Shroud Spacer 4 951-14454 Starter / Shroud Stud M6×99 5 951-11622 Flexible Clamp 6 710-05305 Hook Bolt 7 751-14455 Air Shield 192 710-05303 Self-Tapping Bolt 5.
4P90JUB Crankcase 48 49 50 197 - Gasket Kit - External 51 52 198 - Gasket Kit - Complete 53 199 - Complete Engine 47 189 72 183 185 72 73 186 184 55 183 54 56 57 58 59 62 68 178 60 66 64 65 69 67 36 70 74 63
4P90JUB Crankcase Ref. Part Number Description Ref. Part Number Description 47 951-11499 Upper Crankshaft Seal 69 750-05530 Component Bracket Spacer 48 710-04916 Bolt M6×14 70 951-12235 Breather Hose Assembly 49 951-14456 Breather Cover Plate 72 951-12236 Breather Hose Clamp 50 951-12226 Breather Gasket 73 951-14462 Short Block Assembly 51 951-12685 Umbrella Valve (Incl.
4P90JUB Cylinder Head 197 - Gasket Kit - External 177 198 - Gasket Kit - Complete 176 199 - Complete Engine 173 175 174 172 154 152 153 157 155 175 174 151 162 151 155 153 146 146 157 147 148 149 147 148 149 163 150 171 145 196 164 144 143 173 164 163 170 166 167 168 169 142 165 140 142 142 142 140 140 141 140 38
4P90JUB Cylinder Head Ref. Part Number Description Ref. Part Number 951-14463 Description Cylinder Head Asm 140 710-05315 Bolt M5×10 141 951-12265 Cowl (Incl.
4P90JUB Crankshaft & Crankcase Cover 76 75 79 80 77 91 92 83 5 93 90 82 81 98 104 89 88 87 86 84 99 100 86 101 85 112 113 116 117 103 195 114 115 118 119 117 117 40 102
4P90JUB Crankshaft & Crankcase Cover Ref. Part Number Description Ref. Part Number Description 5 951-11622 Flexible Clamp 98 951-12248 Oil Pump Assembly 75 951-12238 Crankshaft Assembly 99 951-12247 O-Ring 10×2.65 76 951-11969 Main Bearing 100 951-12249 Filter 77 951-10307 Woodruff Key 101 951-12250 Filter Spring 79 951-12239 Dipstick Assembly 102 951-12251 O-Ring 35.5×2.
4P90JUB Carburetor Assembly 134 133 134 132 137 139 132 136 139 I F J K L C M E Q O S P T U V W X Y 200 - Carburetor Kit - Major BB CC DD Z EE GG 42 R N 138 131 B K
4P90JUB Carburetor Assembly Ref. Part Number Description Ref.
4P90JUB Muffler Assembly 191 191 191 193 191 194 48 190 161 161 159 160 158 Ref.
4P90JUB Starter Assembly 9 8 10 11 12 11 12 11 12 24 22 13 24 25 36 34 35 35 33 36 34 37 14 25 15 16 17 32 31 37 18 28 19 29 20 30 Ref. Part Number Description 21 30 Ref.
4P90JUB Ignition & Electrical 40 41 42 43 38 38 38 44 39 45 46 Ref. 46 Part Number Description 38 710-04931 Bolt M6×28 39 951-12220 Ignition Coil Assembly 40 712-04220 Flywheel Nut M16×1.5 41 951-12221 Plate 42 951-12222A Cooling Fan 43 951-12223 Flywheel 44 951-12224 Coil Assy.
Notes 47
NUINE E G T S FA CT O R Y PA R To order replacement parts, call the Customer Dealer Referral Line at 1-877-282-8684 or visit www.cubcadet.com to find the nearest Cub Cadet dealer in your area. CUB CADET LLC, P.O.
