2.3 External I/O
The seven I/O ports of the LoCate-001 device are configured as follows:
Port
#
Designation Type Function Signal Chracterics
1
Output Relay Driver Doors Unlock Relay Pulse active low, 1
second maximum
2
Output Relay Driver Starter Enable/disable
Relay
Level, stays high
or low as
determined by
MIN3 / MIN4
3
Input Digital Crash Sensor, Low Impact Active low,
minimum 1
second. Rise time
less than 150
microseconds
4
Input Digital Crash Sensor, High
Impact
Active low,
minimum 1
second. Rise time
less than 150
microseconds
5
Output Digital Future Assignment
6
Output Digital Future Assignment
7
Input Analogue Future Assignment
Table 3 – I/O Port Configuration
2.4 Event Monitor and Exception Handler
The LoCate-001 unit is programmed to recognize a number of events as
exceptions and use these events to trigger action(s).
Some examples of events are:
• Excessive speed. Note this is not currently supported.
• Door lock open/close, as defined by monitoring of an LoCate-001 digital input.
(This feature is not used with the I/O port assignments shown in Table 3.) Not
currently supported
• Geo-fence violation
• The GPS antenna disconnected.
• Vehicle alarm violated, as defined by monitoring of an LoCate-001 digital input.
Not currently supported. (This feature is not used with the I/O port assignments
shown in Table 3.)
2.5 On Board Diagnostics
The LoCate-001 vehicle unit incorporates on board diagnostics and
troubleshooting support that is accessible by connection to the asynchronous
communications port. The following information is available:
