Dial-up E-Mail Connection: This is handled through
your e-mail settings (nothing else needs to be set in
Netvision).
Note: Web-page-based e-mail services are NOT
supported at the Video Server.
Alarm Message
To and Cc: These are the email addresses of
the person(s) who are to receive the email
alerts from this Video Server (e.g.,
jmartin@mailco.com).
For Multiple "To" or "Cc" Recipients: Use a
semicolon (;) or comma (,) between the addresses (with
NO spaces).
Enable snapshot attachment: Select this to
have a 'snapshot' of the first frame of the
alarm-triggered recording included in the e-
mail. To set the size of the snapshot, click the
[T].
--------------------------------------------------
When finished, click [OK], and then click
[X] to close the list (upper-right corner).
Attention: To recognize any DSR Configuration
changes made while the Video Server software is
running, you may need to restart the software.
Testing Your Settings: To send a sample
email, right-click the Alarm Email Sender on
the Windows Taskbar, and select Test.
Related Topics:
6.2 Responding to Alarm Alerts (Remote Station)
11.2 Remote Users and Permissions
(+ HTTP Server Port);
13.2 Setting up the Alarm Alert Receiver
(Remote Station)
15.2 Set Up the Alarm Alert Caller
18 Scheduled and/or Alarm-Triggered Recording
21 Network and Connectivity Issues
