42 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
Monitor: Pertains to cameras connected
through a switcher. This is the camera ID/port
on the switcher (receiver-driver ID).
AutoFunct: Allows selecting auxiliary
functions that were previously set up (if
available/supported).
AutoPan: Sets the camera for automatic
panning (if available/supported).
AutoFocus: This returns the focus control to
automatic (if available/supported).
Tip: Selecting a pre-set position will also put the
camera into auto-focus mode.
AutoIris: When pressed, the camera will
automatically adjust to changes in brightness
(if available/supported). When not pressed,
the manual brightness (iris) control is in effect.
Tip: Selecting a pre-set position will also put the
camera into auto-iris mode.
Menu: Activates the on-screen menu (for
cameras that support this).
Exception (Pelco-P): For a Pelco-P camera, select
preposition 95 to enable the on-screen menu. To
navigate the menus, use pan up/down and iris
open/close.
