Related Topic: 15.3 Auto Alarm Display (v2.3
SP2)
Alarm Overlay (v2.3 SP2): Special camera subtitles
can be set up to appear for individual cameras
when motion is detected, or an external alarm
occurs.
Related Topic: 15.4 Set Up Alarm Overlays (v2.3
SP2)
Multi-Camera Views: In general, camera
numbers are associated with a specific screen
area. In view-modes that do not show all
cameras at once, only the cameras associated
with different
screen areas can be viewed at
the same time.
Screen Area Þ Camera #s by Screen Area
NetVision Model Ø 1 2 3 4
Plus/Elite: 16 cameras 1-4 5-8 9-12 13-16
Plus/Elite: 8 cameras 1-2 3-4 5-6 7-8
Plus: 4 cameras 1 2 3 4
The indicated cameras will be displayed in sequence in
their respective screen 'quadrant'. E.g., 1, 5, 9, & 13,
then 2, 6, 10, & 14, etc.
On-Screen 'Quadrants':
1 2
3 4
Tip: When showing only 4
cameras, the 8 camera
desktop allows toggling
between odd and even
cameras.
Related Topics
:
8.3 Changing a Camera's View (Pan/Tilt/Zoom);
9 Recording Camera-Views;
17.2.5 Misc. (see "Instant Recording")
Also See
:
8.4 Monitoring Cameras via TV (Spot Monitor)
29 Viewing Cameras through a Web Browser
