Indications in the "Display" Area
(Top-right)
Red Line Above Camera Button: Video
motion-detection enabled (will auto-record
when motion is detected);
Green Line Above Camera Button: Video
motion sensing standing-by (e.g., outside of
scheduled alarm-monitoring times);
Green Camera Number: A camera that is
presently being displayed.
6.4.2
Indications in the "Record" area
(middle-right)
Different types of recordings are indicated by
the colour of each camera button:
• Red Camera #: Alarm/motion triggered
recording ;
• Light Blue Camera #: Pre-alarm recording;
• Yellow Camera #: Instant/manual
recording;
• Green Camera #: Scheduled recording.
Coloured lines above the camera buttons (in
the "Record" area):
Red Line: External sensor being monitored
for this camera--will record if 'tripped'
(and/or
pre-alarm recording is in effect; White
camera #: External sensor only);
Green Line: External sensor monitoring
and/or pre-alarm recording standing-by (e.g.,
outside of scheduled alarm-monitoring times);
Related Topics:
8.1 Viewing Cameras from a Remote Station;
8.2 Viewing Cameras at a Video Server;
9 Recording Camera-Views;
18 Scheduled and/or Alarm-Triggered Recording
6.4
Alarm / Recording Status Indications at a Video Server
(Camera Number Colours)
