118 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
25.3.5
Connection Summary—
NetVision Elite
I / O
TV-Out
to Mux
Odd Cams
Also See:
"25.2.3 Camera
Numbering…"
Even
Cams
TV-In TV-In
MUX
V
ideo
Capture
Out to
TV
12
not used
∗
∗
∗
= Used with 1st board only
Audio Inputs (NetVision Elite): The Video Server PC includes an
integrated sound card with a microphone jack and line-level output
for (self-powered) PC speakers.
Elite units support an optional 4-input line-level audio board.
Bare microphones to connect through a line-level input will each
require a suitable microphone pre-amp.
Related: 25.1 Capture Board Reference
