24.4
Hardware Watchdog Option
Signalling
Outputs
Trouble LED
Standby LED
Comm Error
Normal LED
A
cknowledge
To PC Reset
DC In
(5V max)
e.g., from PC
Status LEDs Acknowledge Button
To capture station
COM port
Use a 2x5 header with
10 conductor flat cable
Pin 1: Align the red wire
with the small triangle.
Wiring (DB9): Pin 1 to
pin 1; 2 to 2, etc.
+
–
