108 NetVision Plus/Elite and Micro DVR v2.3 SP2 User's Guide 21-0400E v2.3.3
24.3.4
Watchdog Configuration
Locator: At the Video Server PC with
NetVision shut down (will prompt for
"Supervisor" login),
Select: (Windows task bar) Start, Settings,
Control Panel, DSR Configuration.
Desktop Link: There should also be a link to this on
your desktop called "NetVision Configuration".
Tips: If you cannot access the Windows task bar,
press Ctrl-Esc (or your 'Windows' key). To view the
names for items on the task bar, click a blank area on
the bar, and then 'hover' your mouse pointer over each
item.
Logon as a "Supervisor" when prompted.
Then, double-click Optional Features Setup
in the list. When the screen appears, select
Watchdog , and then make your desired
selection(s).
Enable Watchdog: Select this if you will be
using the watchdog feature.
Watchdog Selection:
• Software
: Select this if you are NOT using
the hardware watchdog option.
• Hardware
: Select this if you are using the
hardware watchdog option.
• Timer
: This sets how long the watchdog
feature will wait to let the system correct
itself before restarting the Video Server (60-
250 seconds).
Hardware Setup:
• Port
: If you are using the hardware
watchdog option, select the serial port
(COMx) being used for the connection.
--------------------------------------------------
When finished, click [OK], and then click
[X] to close the list (upper-right corner).
Attention: To recognize any DSR Configuration
changes made while the Video Server software is
running, you may need to restart the software.
