Document NO.: WI-FHF-CS-SBA300SL-A

Page 1of 9

MODEL: CS-SBA300SL

REV : A/1

Date : 03 Jun 2017

Lithium Polymer Battery Specification

锂聚合物电池产品承认书

PROJECT NAME 产品名称：CS-SBA300SL

Environmental 环保: ■ROHS □ROHS NO Support

CAMERON SINO TECHNOLOGY LIMITED

Unit 6-7,11F, Ho Lik Centre,66A Sha Tsui Road,Tsuen

WAN, Hong Kong

Tel: +852-2426 9811 3575 8109

Fax:+852 24262911

UTHORIZED SIGNATURE &

COMPANY CHOP

客户认可及签回

APPROVED

批准

CHECKED

审核

PREPARED

制作

Summary of content (9 pages)

PAGE 1
Document NO.
PAGE 2
Document NO.: WI-FHF-CS-SBA300SL-A Page 2of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 TABLE OF CONTENTS / 目录 1. PREFACE/序言 ...................................................................................................................... 2 2. TECHNICAL/FEATURES 技术参数 ....................................................................................... 4 3. TEST/测试 ...........................................................................................................................
PAGE 3
Document NO.: WI-FHF-CS-SBA300SL-A Page 3of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 This product approval sheet has 9 pages ( include the first page ) 本产品承认书共 9 页 ( 含首页 ). This product approval sheet includes technical features, testing method, external connection graph, packing and so on. 本产品承认书包含:技术参数,检测方式,外形尺寸图外部连接图,包装等. Amendment on this product approval sheet content must depend on below condition: 本产品承认书所归属内容的修改必须依据以下条件: 1. Customer’s request or agreement. 客户要求或同意. 2.
PAGE 4
Document NO.: WI-FHF-CS-SBA300SL-A Page 4of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 2.Technical Features 技术参数 Item 项目 Rated performance 性 2.1 Rated Voltage 额定电压 2.2 Discharge Cut-off Voltage 放电终止电压 2.3 Rated Capacity 额定容量 2.4 Limited Charge Voltage 充电限压备注 3.7V 3V 150mAh 0.2C Discharge 0.2C 放电 4.2VDC 先恒流后恒压(CC-CV) 2.6 Standard Charge Current 标准充电电流 2.7 Quick Charge Current 快速充电电流 2.8 Max Discharge Current 最大放电电流 Charge terminal 2.
PAGE 5
Document NO.: WI-FHF-CS-SBA300SL-A Page 5of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 3.Test (测试) 3.1 Testing Environment（测试条件）: 3.1.1 Test time should be no more than one month after receive the battery 测试电池为用户收到后不超过 1 个月的产品. 3.1.2 Testing Environment(测试环境): Temperature(温度) : Relative Humidity(相对湿度) : Atmospheric Pressure(大气压力) : 3.2 15℃--25℃ 45%--85% 76kPa--106kPa Testing Instrument(测试工具): 3.2.1 Voltage meter 0.
PAGE 6
3.3 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 Item Test Method 项目检测方法 Appearance 外观 2 Insulation Resistance 绝缘电阻 Nominal Capacity 标称容量 Charging 充电方式 Discharging 放电方式 4 Page 6of 9 Test method and request (检测方法与要求) 1 3 Document NO.
PAGE 7
8 9 Document NO.: WI-FHF-CS-SBA300SL-A Page 7of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 Vibration Proof Capability 抗振动性能 After standard charged, keep for 0.5h~1h, then installed onto the vibration test with clamps. Equipment parameters of frequency and amplitude are as follows(the frequency is to be varied at the rate of 1oct/min between 10Hz～55Hz, and repeat vibration for 30min. The battery is to be tested in three mutually perpendicular directions): frequency:10Hz～30Hz amplitude: 0.
PAGE 8
Document NO.: WI-FHF-CS-SBA300SL-A Page 8of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 4.Protection Capability Test Method and Request 保护性能检测与要求 1 2 Item Test Method Request 项目检测方法要求 Overcharge Test 过充测试 Over discharge Test 过放测试 Apply a 5V voltage and a 1C charge current on the battery for 10 hours. 用恒压源持续加载 10hs，恒流恒压源电压设定为 5V，电流设定为 1C 的外接电流。 Discharge the battery at 1C to cut off voltage，then discharge with loading 30Ω for 24hs.
PAGE 9
Document NO.: WI-FHF-CS-SBA300SL-A Page 9of 9 MODEL: CS-SBA300SL REV : A/1 Date : 03 Jun 2017 P- C P- C P+ P+ P- 是充放电负极 C 是通讯端口 P+ 是充放电正极 E 是通讯端口 E E 7．PCM Electronic Characteristic / 保护板电气参数 Over-charging Over-discharging Over-current Short-circuit Quiescent voltage voltage protection protection protection time current protection 过放电压保护 figure 短路保护时间静态电流 ≤300us ≤8uA 过充电压保护 4.3V±25mV 过电流保护 2.45V±60mV 3.5A±0.5A 8. Packing / 包装 Packing method, as the customer required.
