Crosley ® LAUNDRY CENTER Owner's Guide LAVADORA Y SECADORA SUPERPUESTAS Manual Del Usuario www.crosley.
Table of Contents Important Safety Instructions.............................................2-4 Washing Procedures........................................................4-5 Stain Removal...................................................................6 Common Washing Problems...............................................7 Drying Procedures .............................................................8 Features ..........................................................................
Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death. Grounding type wall GAS receptacle LAUNDRY Grounding type wall receptacle CENTERS: Do not not under under any circumstances circumstances cut, remove, cut, remove, or bypass or bypass the grounding the groundingprong prong from this from thisplug plug.
Important Safety Instructions Con't • Follow package directions when using laundry products. Incorrect usage can produce poisonous gas--resulting in serious injury or death. - Do not combine laundry products for use in 1 load unless specified on the label. - Do not mix chlorine bleach with ammonia or acids such as vinegar. Washing Procedures • Follow the guidelines below for preparing the wash load. • Read the Washer Operating Instructions for operating your specific model.
Washing Procedures (continued) 6. Add laundry load to washer. • • • Do not load items higher than top of agitator vanes. • Dry load level should not be higher than the top of agitator vanes. Do not overload the washer. Do not put items on top of agitator or wrap them around it. Load items evenly. Combine large and small items in a load. Load large items first. Large items should not be more than half the total wash load. When washing a single heavy item, add 1 or 2 towels to balance the load. 7.
Safe Stain Removal Procedures Do not combine stain removal products. Follow fabric care label instructions. To reduce the risk of fire, electrical shock, or serious injury to persons or property, comply with the basic warnings listed in Important Safety Instructions and those listed below. • Read and comply with all instructions on stain removal products. • Keep products in their original labeled containers and out of children's reach. • Thoroughly wash any utensils used.
Common W ashing Pr oblems Washing Problems Many washing problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing results, follow these suggestions provided by The Soap and Detergent Association.
Drying Procedures • Follow the guidelines below for preparing the load for drying. • Read the Dryer Operating Instructions for operating your specific model. • Always read and follow fabric care labels and laundry product labels. To reduce the risk of fire, electrical shock, or serious injury to persons or property, comply with the basic warnings listed in Important Safety Instructions and those listed below. 1. Prepare items for drying. Follow fabric care label instructions.
Cycle Signal Control (some models) Features When the Cycle Signal Control is ON, a signal will sound at the end of each cycle and during the Press Saver setting (some models). The volume is adjustable on some models. Drum Light (some models) A drum light will come on whenever the door is opened to illuminate the dryer drum during loading and unloading. Closing the door turns off the light. Drying Rack (some models) Use the drying rack to dry items which should not be tumble dried. 1.
Care and Cleaning To reduce risk of fire or serious injury to persons or property, comply with the basic warnings listed in Important Safety Instructions, page 2, and those listed below. • Before cleaning the washer or dryer interior, unplug the electrical power cord to avoid electrical shock hazards. • Do not use any type spray cleanser when cleaning dryer interior. Hazardous fumes or electrical shock could occur. Inside the Washer • Remove items from the washer as soon as the cycle ends.
Winterizing Instructions If the laundry center is stored in an area where freezing can occur or moved in freezing temperatures, follow these winterizing instructions to prevent damage to the laundry center: Follow Winterizing Instructions for cold weather care. 1. 2. 3. 4. 5. 6. 7. 8. Turn off water supply faucets. Disconnect hoses from water supply and drain water from hoses. Plug electrical cord into a properly grounded electrical outlet.
OCCURRENCE POSSIBLE CAUSE SOLUTION WASHER - OPERATING (continued) Cycle selector is not in correct position. Move indicator clockwise slightly. Pull out knob. Motor is overheated. Washer motor will stop if it becomes overheated. It will automatically restart after a cool down period of up to 30 minutes (if washer has not been manually turned off). Washer won't spin. Lid is not completely closed. Close lid completely. Safety lid lock must not be broken. Residue left in tub. Heavily soiled items.
OCCURRENCE POSSIBLE CAUSE SOLUTION Electrical power cord is not securely plugged in or plug may be loose. Make sure the plug fits tightly in wall outlet. House fuse blown or circuit breaker tripped. Reset circuit breaker or replace fuse. DRYER Dryer does not start. Make sure electrical line is not overloaded and the dryer is on a separate circuit. Dryer runs but won't heat. Drying cycle takes too long, outside of the dryer feels too hot or smells hot. Thermal limiter tripped.
® CROSLEY WARRANTY Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained inaccordance with the provided instructions. Exclusions This warranty does not cover the following: 1.
