User manual

7
POWERED SPEAKER
Setup
Plug phono plugs from Mixer into Powered Speaker into Aux 1
or Aux 2.
Set all controls to Quarter past .
MIC INPUT
For use only when using as a PA system.
Left off unless in use.
MIC CHANNEL
To adjust AUX 1 use GAIN 1.
To adjust AUX 2 use GAIN 2.
Both BASS and TREBLE can be used on both AUX outputs.
Master control is used to adjust the volume.
If more than one speaker is to be used, plug the speaker cable
from the external (EXT LS), to the INPUT on the second (Slave)
speaker (see below).
SLAVE SPEAKER
Harmoniser
Harmoniser Gain Control should be set to 12 o clock
Harmoniser Gain Control
