SPARK PLUG
!
WARNING: Only use recommended spark plug or
equivalent. DO NOT use spark plugs that have improper
heat range.
1. SPARK PLUG - Clean any dirt from the spark plug cap and
spark plug base.
2. Remove the spark plug cap.
3. Using socket wrench to loosen and remove the spark
plug.
4. Inspect the spark plug and spark plug washer, if it’s
damaged or worn, replace with a new one. Clean the
spark plug with wire brush before replacing.
5. Check spark plug gap. Carefully bend side electrode to
adjust the gap if necessary.
Spark plug gap: 0.6mm - 0.8mm
Spark Plug ghten Torque: 9-12 N.m
SPARK PLUG: LG E6RTC
6. Carefully thread the plug into the engine by hand.
7. Aer the spark plug is seated, use spark plug wrench to
ghten the plug.
8. Aach the spark plug wire to the plug.
9. Replacement spark plug: LG F6RTC
Pg. 26
