Brochure

180AMP CROMMELINS WORKSTATION DIESEL
GENERATOR
www.crommelins.com.au
Authorized Dealer
SPECIFICATIONS
MODEL NUMBER WS180YDEH
Max. Watts (w) 4000w
Cont. Output (w) 3200w
Starting System Electric Start
Phase Single
Fuel Type Diesel
10amp outlet s/phase 1x 10Amp
15amp outlet s/phase 1x 15Amp
Alternator Sincro
Voltage (V) 240v - 50hz
Air Compressor CFM 7.7CFM
Welding Amps (A) 60 to 180 Amp
Engine Power/Model 10.0hp L100
Engine Brand Yanmar
Fuel Tank (L) 5.4L
Noise Level (dB @ 7m) 97db at 1m
Weight (kg) 170kg
Dimensions (LxWxH)
930 x 830 x
720mm
Package (LxWxH)
930 x 830 x
720mm
Manufacturers Warranty 2 Years
Barcode 9336493006764
The 180 Amp workstation diesel generator is the
perfect combination for a mobile workshop or
service vehicle for mining applications. It comes
with a 5kvA Generator, Welder, 7.7cfm Air
Compressor all built into an Australian fabricated
steel frame.
STANDARD FEATURES
40L Air compressor (7.7cfm)
Power generation
5m Welding leads
Electric start with AGM battery
Weatherproof outlets with RCD
Sincro brushless alternator
33mm Australian fabricated steel frame
Cable holders and lifting hook
2 Years manufacturer’s warranty
Assembled and tested in Australia
IDEAL FOR
Agricutural
Air compressor equipment
Welding on-site
Multi-purpose use
Service vehicles
INDUSTRY
Hire and Rental
Construction
Building
Agriculture
