Installation guide

Decorator Keypads Crestron C2N-DBF12 & C2N-DBN12
2
•
Decorator Keypads: C2N-DBF/N12 Operations & Installation Guide – DOC. 6200C
Available Colors/Textures
COLOR/
TEXTURE
MODEL #
SUFFIX
MATCHING LUTRON
®
FACEPLATE COLOR
Almond Smooth A-S Light Almond (LA)
Black B Black (BL)
White Smooth W-S White (WH)
Specifications
Specifications for the C2N-DBF/N12 are listed in the following table.
C2N-DBF/N12 Specifications
SPECIFICATION DETAILS
Power Requirements
Cresnet Power
Usage
3 Watts
(0.125 Amps @ 24 VDC)
Default NET ID 71
Minimum 2-Series Control
System Update File
1, 2
Version C2-2.004.CUZ or later
Environmental
Temperature
Humidity
32° to 113° F (0° to 45° C)
10% to 90% RH
(non-condensing)
Enclosure 1-gang mountable in a standard
electrical box;
requires decorator style faceplate
(provided by others)
Dimensions
(without faceplate)
Height
Width
Depth
4.16 in (106 mm)
1.79 in (46 mm)
1.53 in (39 mm) without
connector
Weight 2.60 oz (75 g)
(Continued on following page)
