Installation guide

Crestron C2N-DBF12 & C2N-DBN12 Decorator Keypads
Operations & Installation Guide – DOC. 6200C Decorator Keypads: C2N-DBF/N12
•
1
Decorator Keypads:
C2N-DBF12 & C2N-DBN12
Introduction
Decorator Keypads provide a cost-effective room control solution for
Adagio
®
and other Crestron
®
AV distribution systems. The
C2N-DBF12 includes a set of 30 assorted button caps labeled for AV
source selection and control functions. The C2N-DBN12 complements
the C2N-DBF12, adding a set of numeric buttons for direct entry of
channels, titles and tracks.
For simplicity within this guide, the term “C2N-DBF/N12” is used
except where noted.
Features and Functions
NOTE: Keypads can also be mounted in multigang electrical boxes.
1. C2N-DBN12 only.
2. C2N-DBF12 only.
• Simple design with 12 buttons and feedback LEDs
• New color-matched “smooth” finishes
• Includes pre-labeled button caps for numeric entry
1
• Includes 30 pre-labeled button caps — provides six source select
and six AV control buttons
2
• Optional numeric entry keypad
2
• Fits standard electrical gang boxes and decorator style faceplates
• Available in smooth almond, black and white finishes
•
Easy Cresnet
®
wiring
