Operation
The C2N-DBF12 serves as a source keypad, providing a cost-effective
room control solution for Adagio and other Crestron AV distribution
systems. It includes a set of 30 assorted button caps labeled for AV
source selection and control functions.
The C2N-DBN12 can be used to expand the capabilities of the source
keypad and is ideal for audio device functions such as selecting a
particular CD track number or a certain CD from a CD changer.
All buttons on the keypad are functionally identical and have light
emitting diodes (LEDs) that serve as user feedback indicators. Each
LED’s illumination (on/off) is independently addressable and is
programmable using SIMPL Windows.
In the program, the intensity level for all of the button LEDs can be set
from 0 to 100%.
