Crestron C2N-DBF12 & C2N-DBN12 Decorator Keypads
Operations & Installation Guide – DOC. 6200C Decorator Keypads: C2N-DBF/N12
•
7
The keypads come fully assembled and each has 12 buttons with LED
windows (refer to illustration on page 4). The C2N-DBF12 has six source
selector buttons, an ON-OFF button, a MUTE button, and device
transport control and volume control buttons. A kit with additional source
buttons for the C2N-DBF12 is also provided (refer to illustration on
page 6). The C2N-DBN12 has a CLEAR button, an ENTER button, and
numeric digit buttons 0 through 9.
