Crestron C2N-FTB FlipTop Control Center with Cresnet
®
Configuration Software
Have a question or comment about Crestron software?
Answers to frequently asked questions (FAQs) can be viewed in the Online Help
section of the Crestron website. To post a question or view questions you have
submitted to Crestron’s True Blue Support, log in at http://support.crestron.com.
First-time users will need to establish a user account.
Configuration is easy thanks to Crestron’s Windows-based programming
software. Crestron SystemBuilder™ software creates a complete project, with
no special programming required. SystemBuilder completes all necessary
programming for a base system including all touchpanel screens and the control
system program. The program output of SystemBuilder is a SIMPL Windows
program with much of the functionality encapsulated in macros and templates.
Once SystemBuilder creates the project, the system interfaces and program logic
can be customized in SystemBuilder or can be easily modified with Crestron
development tools (i.e., SIMPL Windows and Crestron VisionTools
®
Pro-e (VT
Pro-e) software packages).
SystemBuilder comes with templates for all supported interfaces. If a user
wishes to create a touchpanel project using templates with a different look-and-
feel, this can be accomplished by making a custom template. This custom
template can then be used by SystemBuilder to create the final project files to be
loaded into the panels. Alternatively, VT Pro-e can be used to tweak projects
created with the SystemBuilder or develop original touchpanel screen designs.
Earliest Version Software Requirements for the
PC
NOTE: Crestron recommends that you use the latest software to take advantage
of the most recently released features. The latest software is available from the
Crestron website.
NOTE: Crestron software and any files on the website are for Authorized
Crestron dealers and Crestron Authorized Independent Programmers (CAIP)
only. New users are required to register to obtain access to certain areas of the
site (including the FTP site).
The following are the earliest useable software version requirements for the PC:
• (Optional but highly recommended) SystemBuilder version 2.0
(Requires SIMPL Windows, VT Pro-e and Crestron database).
• SIMPL Windows version 2.05.22 or later. Library 320 and SIMPL+
®
Cross Compiler version 1.1 are required.
• Crestron Database version 16.4.1 or later. Required by SIMPL
Windows.
• (Optional, if system was programmed without SystemBuilder 2.0)
Installer’s Toolbox version 1.0 or Viewport version 3.35.
• Crestron Engraver version 2.3 for button engraving.
