Installation guide

FlipTop Control Center with Cresnet
®
Crestron C2N-FTB
Indicators
PWR (Power)
This LED illuminates when 24 volts DC is supplied to the C2N-FTB from
Cresnet.
NET
This LED illuminates when communication between the control system and the
C2N-FTB is established (the unit is polled on the network). Illumination
indicates that the SIMPL Windows program currently loaded has a network
device defined at the same Net ID as the C2N-FTB.
Bargraphs
Two sets of eight-segment programmable red LEDs are provided that can be
programmed to display audio level settings. The LEDs display is proportional to
the input and can be set from zero to 100%.
SETUP LED and Pushbutton
The C2N-FTB is Touch-Settable ID-ready. A SETUP pushbutton is located on
the bottom side of the C2N-FTB. The SETUP pushbutton and its associated
LED are used for setting a units network ID during the initial configuration of a
Cresnet system or when the device is being added/replaced. Refer to “Method B
(Touch Settable ID)” on page 9 for detailed information.
Industry Compliance
As of the date of manufacture, the C2N-FTB has been tested and found to
comply with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Setup
Network Wiring
CAUTION: In order to ensure optimum performance over the full range of
your installation topology, Crestron Certified Wire, and only Crestron Certified
Wire, should be used. Failure to do so, may incur additional charges if support is
required to identify performance deficiencies as a result of using improper wire.
CAUTION: Provide sufficient power to the system. Insufficient power can lead
to unpredictable results or damage to the equipment. Please use the Crestron
Power Calculator to help calculate how much power is needed for the system
(http://www.crestron.com/calculators).
