User's Manual

Single/Dual-Channel Wireless Mic Receiver Crestron MP-FS-RX1/RX2
Specifications
Specifications for the MP-FS-RX1/RX2 are listed in the following table.
MP-FS-RX1/RX2 Specifications
SPECIFICATION DETAILS
Communications
Wireless
RF
2.4 GHz ISM Device; 79 channels, FHSS
(2402 to 2480 MHz)
IR 38 kHz (requires MP-FSIR IR Beacon Sensor*)
Range (typical)
50 ft (~15 m) indoor, subject to site-specific
conditions
Wired
USB
USB host port for firmware update and
configuration
Audio
A-D/D-A Conversion 16-bit, 44.1 kHz
Master Volume Range -55dB to +20dB
Bass Gain Range
±15dB @ 100Hz
Treble Gain Range
±15dB @ 10kHz
Ducking Adjustment
Software adjustable Threshold, Depth, Attack,
and Release
Alert Tone
Software configurable functionality
Frequency Response
20 Hz to 20 kHz ±0.5 dB
S/N Ratio
75 dB 20 Hz to 20 kHz A-weighted
THD+N
0.7% 20 Hz to 20 kHz
Output Power
15 Watts per channel at 8 or 4 Ohms
Amplifier Protection
Electronic short-circuit and overload protection
Power Requirements
Power Pack
2.0 Amps @ 24 Volts DC, 100-240 Volts AC,
50/60 Hz power pack, included
Environmental
Temperature 41° to 104° F (5° to 40° C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 35 BTU/Hr
Enclosure
Chassis Metal with polycarbonate label overlay
Faceplate Plastic with polycarbonate label overlay
Mounting Freestanding
Dimensions
Height 2.36 in (60 mm)
Width 8.12 in (207 mm)
Depth 5.95 in (152 mm)
(Continued on following page)
