Operating instructions

2-1
Hardware Setup
is section describes the front and back connections of the CDVS-4216H,4216L, 4208, 4204 Embedded
DVR.
USB PortsDVD/CD-RW Drive Front Panel Controls
On/O Button
Video Output
cable connection
Video Inputs 1 - 16
Spot monitor
Output
Audio Out
Audio Input
Power plug
connection
Sensor/Relay/Ground/
422/485 connections
LAN connection
Two way
Audio In
NTSC/
PAL
Mon.
out
S-Video
Out
VGA
out
USB
ports
Front Panel Controls
Back Panel Controls
(4216H shown)
4216H 16 Channel Embedded DVR
e images that follow show the hardware connections for the 16 channel embedded DVR.
Audio Out
