User`s guide

93
Learning the Basics
Using the AccuPoint II
Using the AccuPoint II
The AccuPoint II keys
Accupoint II pointing device—Enables you to move the cursor
and to select items on the screen. (If you would prefer to use a
mouse or trackball, you can connect one to the computer’s serial
port or PS/2 port. See “Using a mouse” on page 62.
To move the cursor, gently push the pointing device in the
direction you want the cursor to move. Pushing harder on the
pointing device moves the cursor faster.
Programmable buttons—Each button can be programmed to
perform a function you select. To program these buttons:
1 Double-click the mouse icon in the task tray.
2 Select the Buttons tab.
3 Under Button Assignments, choose the button to be
programmed, and select its new function from the pull-down
menu.
4 Click OK. The button is now programmed with the function
you chose.
Primary button—Performs the same function as the left button
on a mouse.
AccuPoint II
Primary button
Secondary button
Programmable button
Programmable button
pointing device
