Playing / Recording Music
Add studio quality audio sound tracks or voice tracks to your video clips or home videos with studio-
grade components which include 123dB analog-to-digital converters (ADCs) with RCA Aux-in and optical
input for outstanding recording quality.
Connecting your external device to the Sound Blaster ZxR
You can play music from, and/or record music to external devices (for example, Digital Audio Tape
player/recorder) by connecting them to your Sound Blaster ZxR.
1
BASS TREBLE BALANCE
VOL
POWER
INPUT MODE
PROGRAM
INPUT SELECTOR
VIDEO L R
EFFECT
PHONE
2
3
Jack, Connector or Cable Description
1. Optical S/PDIF Out jack Connects to recording devices with
optical connectors (for example,
DATrecorders, MDrecorders or
external hard disk recorders).
2. Optical cable Connects the playback or recording
device to your Sound Blaster ZxR.
3. Optical S/PDIF Out jack Connects to the Optical S/PDIF Out jack
on your audio card.
Using Your Sound Blaster ZxR 25
