SPA-100 SPARE TOOLING
Suggested Spare tooling for the SPA-100 machine is as follows:
A. One each machine – 901306 micro switch
B. Two each machine - 902300 micro switch
C. One pair of contact punches on most used product
8-position 901053 contact driver
TROUBLE SHOOTING TIPS
Motor will not run Check the relays in rear of machine. They may have
come loose during shipment.
Ram cycling continuously Check the micro switch at the top of machine for
up and down or drifting proper placement and/or not working. Check break
pac relay to ensure it is working properly. (see
adjustment notes below)
No cycle on auto Micro switch in nest may be faulty, or may be
pushed too far. There maybe lint build-up. Check
both nests.
Testing displaying error; Tooling may be out of adjustment, causing
product looks fine plastic skiving of the ribs which insulates the
test probes from the contacts.
If test leads don’t have enough bend on the
front, they may not snap down between the ribs
to make continuity with the contacts in the plug.
